www.heinner.com 65W, 50Hz, 220-240V
5
4. Screw two 4 x 30mm screws on the wall with wall plugs to fix the hood, then use two
4mm x 40mm screws to fix the inside chimney bracket. See Pic 2.
5. Equip the Valve.Install the expansion pipe onto the cooker hood. Fix the expansion pipe
on the valve by cable tie. See Pic 3.
6. Install the outside chimney bracket onto the outside chimney, here should be sure the
inside chimney can be flexed freely. See Pic 4.
7. Make the hood hang on the wall in the fixed position, adjusting the cooker hood
position, fix the cooker hood with safety screws.
The safety vents are positioned on the back housing, with diameter of 6mm.
8. Adjust the height of the inside chimney to the position of the inside chimney bracket
and fix on it by screw. See Pic 6.
Expansion pipe
Knob on the top
Pic 3
Inside chimney
Outside chimney bracket
Outside chimney
Pic 4
Pic 5
Pic 6
