100
www.hecht.cz
POWER TOOLS, WELDING SHIELD
* Maximum working time without load with 2 Ah battery.
HECHT 8950
500 W
electric 230 V/50 Hz cut depth at 90° 115 mm
power input 500 W cut depth at 45° 65 mm
saw blade length 1712 mm table size 302×304 mm
no load speed 2982 min
-1
weight 24 kg
HECHT 008950
SAW BLADE FOR
HECHT 8950
HECHT 008950A
STAND FOR
HECHT 8950
BAND SAW
HECHT 835
2600 W
CUT OFF SAW
electric
230 V/50 Hz
blade diameter 355 mm
power input 2600 W mitre cuts -30°– +45°
no load speed 4100 min
-1
weight 12,3 kg
HECHT 00835
SAW BLADE
FOR HECHT 834
HECHT 8400
400 W
Accessories included
electric 230 V/50 Hz spindle head threat M18
power input 400 W
max. workpiece
length / diameter
1000 / 350 mm
no load speed
890/1260/
1760/2600 min
-1
weight 21 kg
ELECTRIC WOOD LATHE
70 cm
30 cm
HECHT 8410
370 W
electric 230 V/50 Hz swing over bed 180 mm
power input 250 W
distance between
centers
300 mm
no load speed
100–1100 min
-1
,
100–2500 min
-1
cross slide travel /
compound travel
65 / 55 mm
spindle taper MT2, MT3
weight 37 kg
ELECTRIC MINI LATHE
Standard accessories
included
HECHT 008410A
Lathe knife set 8x8 mm
HECHT 008410B
Swivel tip MT2
HECHT 008410C
Clamping disc Ø 160 mm
HECHT 008410D
Clamping set for disc Ø 160 mm
HECHT 008410E
4-jaw chuck 100 mm
HECHT 008410F
Fixed bezel
HECHT 008410G
Sliding bezel
HECHT 008410H
Fixed tip MT3
HECHT 008410I
Drill chuck 13mm + MT2
Accessories for
HECHT 8410
30 cm
114 cm
60 cm
45 cm
HECHT 8420
960 W
electric 230 V/50 Hz swing over bed 250 mm
power input 550 W
distance between
centers
550 mm
no load speed
125–2000 min
-1
cross slide travel /
compound travel
110 / 75 mm
spindle /
tailstock taper
MT2 / MT3
weight 145 kg
ELECTRIC BENCH LATHE
Standard accessories
included
HECHT 008420A
Lathe knife set 10x10mm
HECHT 008420B
Swivel tip MT2
HECHT 008420C
Clamping disc Ø 220 mm
HECHT 008420D
Clamping set for disc Ø 220 mm
HECHT 008420F
Fixed bezel
HECHT 008420G
Sliding bezel
Accessories for
HECHT 8420
HECHT 900255
filter size 110 × 90 mm UV / IR DIN 16
window
dimensions
92 × 42 mm
dark state shade
DIN 9–DIN 13
response time ≤ 1/25000 s weight 0,5 kg
solar cells + battery, sensitivity control, fully automatic on/off
WELDING SHIELD
Welding + grinding
function
