The Heat-Fab Saf-T Liner system is intended for use in conjunction with any residential building,
heating appliance burning gas, liquid or solid fuels, such as a woodstove, fireplace insert, or an oil or
gas fired central heating furnace, vented through
masonry chimneys only. These heating appliances
may not exceed the maximum continuous flue-gas outlet temperatures of 1000
O
F or cause
condensation of corrosive acids on the liner, or create positive pressures in the chimney system.
Saf-T Liner is a high quality U.L. tested and Listed stainless steel lining system designed for relining existing
masonry chimneys. It satisfies code requirements as a substitute for 5/8" fireclay liners and has undergone
extensive testing to make it the leader in the stainless steel chimney lining industry. Heat-Fab recommends that
the installation of Saf-T Liner be performed by an experienced professional who works with chimney and
woodstove related products on a regular basis. Saf-T Wrap is a safe, high quality, easy to install ceramic
insulation jacket for stainless steel lined masonry chimneys. Saf-T Wrap when used in conjunction with Saf-
T Liner will upgrade a chimney to an HT type chimney system. The following instructions are intended as a guide
to assist a qualified professional installer. Check your local building codes and contact local building or fire
officials to obtain any required permits. Warning: Incorporation of parts or materials not manufactured or
supplied by Heat-Fab may not provide a Listed system. Order Heat-Fab’s installation videotape for further
information, available in VHS format.
SAFETY FIRST
The National Fire Protection Association Standards Nos. 54 and
211 require the chimney to extend at least 3 feet above the highest
point where it passes through the roof, and at least 2 feet higher than
any portion of the building within 10 feet (Fig.1).
The Saf-T Liner should not extend more than 6 inches above the
masonry chimney. Any additional flue liner height above the
masonry chimney will create condensation resulting in the buildup
of excessive creosote.
Do not connect more than one solid fuel burning appliance to a single chimney flue and do not connect gas or
liquid fired appliances to chimney flues serving a solid fuel burning appliance.
Wear eye protection and heavy gloves throughout installation. Wear eye protection and dust respirator
whenever in contact with creosote, soot, mortar or insulation. Caution must be used when working on a roof.
Proper and safe scaffolding should be used for a safe installation. All ladders should be secured to the building.
Check overhead for antennas, power lines, or other obstacles before erecting the ladder and installing liner.
CHIMNEY PREPARATION
Lay out ground cloths to protect the inside of the home before sweeping the chimney. Clean and remove all tar
glazed creosote and soot deposited on the internal chimney walls, and smoke chamber of the fireplace, failure
to throughly clean the chimney before installing a new liner system may lead to fire and or smoke damage to
the home. Always use a dust respirator when in contact with soot and creosote.
Inspect the chimney for the following structural weaknesses before it is lined:
• Loose or eroded mortar
• Cracks in the masonry
• Missing bricks
• Internal obstructions that could inhibit installation
Repair all structural weaknesses before proceeding with installation of Saf-T Liner.
10 Feet
2 Feet
3 Feet
Fig. 1
