23
Design and function
Key assignment / Quick guide
Switching on
Press
button for approx. 3 seconds until acoustic signal sounds twice, then release
Switching off
Press
button for approx. 3 seconds until acoustic signal sounds once, then release
Starting measurement
Press
button, OK disappears from display
Open/close menu
Press button
Navigate upwards within menu/ascending numerical values
Press button
Navigate downwards within menu/descending numerical values
Press button
Confirm instructions
Press
and
at the same time
Rotate the display
Press
and
at the same time
5. Menu structure SmartTAC - 2sTAC
1st Level 2nd Level 3rd Level 4th Level 5th Level 6th Level 7th Level 8th Level 9th Level 10th Level
1. Mode
Torque
Rotation angle
2. Torque
Track
Peak
Target value
000.0 (unit)
Right (+)
Left ( - )
Tolerance
+/-00.0%
Rotation angle
check
No
Yes
Snug torque
000.0 (unit)
Lower rotation
angle 000.0
(unit)
Upper rotation
angle 000°
3. rotation angle
Snug torque
000.0 (unit)
Rotation angle
000°
Right (+)
Left ( - )
Tolerance
+/- 00°
Torque
check
No
Yes
Lower torque
000.0 (unit)
Upper torque
000.0 (unit)
4. Unit
Nm
Lbfft
Lbf in
Kqfm
5.
Effective
length
Effective length
000.0 mm
6. Signals
Threshold
00%
Buzzer off
Buzzer on
Vibration off
Vibration on
7. Reset
Reset
Factory setting
Off
On
8.
Display dim
-
ming
On
Off
9. Stand-by
Stand-by
00min
10. Memory
Display values
Delete values
Delete all
Memory display
Memory display
Delete all
11. Parameters
Parameter 1 to
Parameter 25
Inactive
(only display)
Active
(only display)
Torque
Rotation
angle
Programming like in sections
2 and 3.
12. Workflow
Workflow 1
to
Workflow 25
Inactive
Active
A1.1 P-
A1.2 P-
etc.
13. Date/time
dd.mm.yy
hh:mm:ss
14. Version
Displays the
software
version
2nd page with
serial number,
calibration date,
quantity, triggers
15. Language
German
English
French
Italian
Chinese
16. Code Old 0000 New 0000
17. Menu access Block Code 0000
18. Bluetooth Bluetooth
