Design and function
1. Technical data / tool components
Technical Specification SmartTAC System 7000 sTAC Top Version - 2sTAC
HAZET No.
7280-2sTAC 7281-2sTAC 7290-2sTAC 7291-2sTAC 7292-2sTAC 7294-2sTAC 7295-2sTAC 7250-2sTAC
Torque display range (Nm)
0.5 - 10 1.25 - 25 2.5 - 60 5 - 100 10 - 200 20 - 400 32.5 - 650 100 - 1000
Torque measuring range (Nm)
1 - 10 2.5 - 25 5 - 60 10 - 100 20 - 200 40 - 400 65 - 650 200 - 1000
Torque units
Nm; lbf.ft; lbf.in; kgf.m
Uncertainty of measurement for
Torque measuring range
± 2% / ± 1 Digit ± 1% / ± 1 Digit
Adjustable tolerance range for Torque
± 1% to ± 10%
Uncertainty of measurement for
rotation angle measuring range
± 1 % / ± 1 °
Adjustable tolerance range for
rotation angle
± 1° to ± 90°
Insert square /
installed reversible ratchet*
9 x 12 9 x 12 9 x 12 9 x 12 14 x 18 14 x 18 14 x 18
4
3/4"
Adjusted with insert tool holder
Effective length (WL) / gauge dimension lw (mm)
6413-1
6413-2
17.5
6413-1
6413-2
17.5
6402-1 (3/8")
30
6402-1 (3/8")
30
6404-1 (1/2")
38.5
6406 (3/4")
44
6406 (3/4")
44
—
86,5
Length with/without insert
tool (mm)
290.5 / 260 290.5 / 260 347 / 302 428 / 383 578.5 / 520 1021 / 945 1217 / 1141 1772*
Weight with/without insert
tool, approx. kg
0.4 / 0.35 0.4 / 0.35 0.8 / 0.7 0.9 / 0.8 1.3 / 1.0 3.2 / 2.3 5.9 / 5.0 9.0
+
Available memory incl.
date and time
up to 3000 measurements
Possibility to program
sets of parameters / workflows
25 / 25
Low Energy Bluetooth interface
u u u u u u u u
USB-C interface
u u u u u u u u
Menu languages
German, English, French, Italian, Chinese
Protection rating
IP 40
Rechargeable battery, can be charged
directly in the device
Rechargeable Li ion battery, type 14650 / 3.7 Volt / 1100 mAh
2. Included in delivery
• Torque wrench with built-in angle gauge with operating
instructions, examination certificate, rechargeable Li ion
battery, USB 3.1 A-C cable and insert reversible ratchets
as per the table above, in the case.
HAZET No.
7280-2sTAC 7281-2sTAC 7290-2sTAC 7291-2sTAC 7292-2sTAC 7294-2sTAC 7295-2sTAC 7250-2sTAC
Supplied with
6401-1 (1/4")
19.5
6401-1 (1/4")
19.5
6402-1 (3/8")
30
6402-1 (3/8")
30
6404-1 (1/2")
38.5
6406 (3/4")
44
6406 (3/4")
44
--
3. Function / signal levels
• The torque wrench with built-in angle gauge has four signal
levels (combined visual, audible and physical signals) that are
activated when configured values are reached.
• The visible signals are shown below the matted ring on the
handle, the audible signals are generated by a buzzer in the
housing and the physical signals are created by a vibration
motor in the handle.
• The torque wrench with built-in angle gauge has two
selectable operating modes: "Torque" and "Rotation angle".
• In "Torque" mode, you can select the torque programs
"Torque track" and "Torque peak".
• A snug torque (starting point for the angle measurement), a
target value for the rotation angle and a ± tolerance for the
rotation angle in "°" (degrees) are entered in the “Rotation
angle” program.
• A yellow light flashes once upon reaching the snug torque
and therefore the start of angle measurement.
• The first signal level – yellow flashing light, acoustic signal
and low-frequency vibration – starts when the applied
torque reaches the set threshold value, e.g. 80% of the
lower value of the target value range. Once the first signal
level is reached, you should reduce the tightening speed
and pay closer attention to the force you are applying, the
display and the signals of the torque wrench with built-in
angle gauge. The lower the target value and the higher
the threshold, the quicker the first signal level is exceeded.
• The second signal level – green flashing light, acoustic sig
-
nal and mid-frequency vibration – indicates that the applied
torque is within the target value range. Once the second
signal level is reached, stop screw action in this area.
