ASSEMBLY INSTRUCTIONS
SAFETY NOTICE
ASSEMBLY INSTRUCTIONS
GENERALASSEMBLY
Before using the mower, read this owners handbook carefully.
Pay particular attention to the safety precautions.
Spark Plug lead
Air Cleaner
Engine Cowl
Serial No. Label
Fuel Cap.
Height of Cut Adjuster.
Handlebar Securing Knob.
Engine Start-Grip.
Variable Speed Control (399S only)
Engine Stop lever.
Handlebar.
Ground Drive Clutch Lever (398S & 399S only)
Throttle Control
Grassbag Assembly.
Rear Deflector.
Handlebar Height Adjusting Knob.
Handlebar Height Adjusting Fixing Screw.
Oil Filler Cap and Dipstick
Muffler Guard
1D399S
1
2
3
4
5
6
7
8
9
10
15
16
17
18
19
14
13
12
11
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
