13

OPERATION

Move the Master Power Switch ⁄

(marked Power) to the “

•

” (On) position.

The SUB-TS10 subwoofer will automatically

turn itself on or go into Standby mode,

depending on whether or not a signal is

being sent to it by your receiver or surround

processor, and provided that the Music-

Sense On/Off Switch ¶ is moved to the

right so that it is in the AUTO position.

When your receiver or amplifier is off, or is

not sending program material to the sub-

woofer, the subwoofer will be in Standby

mode and the LED Indicator ª on the

amp panel will turn red. When the sub-

woofer senses an audio signal,

it will auto-

matically turn itself on and the LED

Indicator ª will turn green. If the sub-

woofer does not sense a signal after

approximately twenty minutes,

it will auto-

matically go into Standby mode.

When the Music-Sense On/Off Switch

¶ is switched to the ON position, the sub-

woofer will remain on, whether or not pro-

gram material is playing.

If you will be away from home for an

extended period of time, or if the sub-

woofer will not be used, switch the Master

Power Switch ⁄ to the OFF position.

Volume

Volume can be adjusted using the

Subwoofer-Level Control ‚, as shown

below.

Additional Bass Adjustments

In addition to the volume adjustments

described above, the SUB-TS10 subwoofer

includes a Phase Switch ∞ and a Filter

Switch § that can be used to adjust the

bass response to suit your listening environ-

ment or taste.

In most situations, the Phase Switch ∞

should be left in the NORMAL position. If

you suspect that the subwoofer is playing

out of phase with the other speakers, which

would tend to diminish bass response, try

placing this switch in the REVERSE

position. There is no harm in experimenting,

and you may return the switch to the

NORMAL position at any time. If you

rearrange your room and reposition the

speakers, it would be a good idea to check

whether they are in phase by flipping this

switch.

The High-Cut (Low-Pass) Filter Switch

§ limits the frequencies of the audio sig-

nal inputted to the subwoofer to the low

frequencies that the subwoofer reproduces

best. This allows the subwoofer to perform

more efficiently, and with superior bass

reproduction, minimizing distortion that

might occur if the subwoofer attempted to

reproduce higher frequencies. This switch

should be left in the ON position, except:

1. When the

SUB Input £ is being used,

in which case it has no effect, or

2. When the

Speaker-Level Inputs ™

or the Line-Level Full-Range Inputs ¢

are being used with a crossover or filter

on board the receiver or processor. In these

two circumstances, place the switch in the

OFF position.

MIN MAX

Subwoofer

Level

MIN MAX

Subwoofer

Level
