English

Wall mount (see page 33)

Ceiling mount (see page 35)

Safety Notes

!

Gloves should be worn during installation to prevent

crushing and cutting injuries.

!

The product may only be used for bathing, hygienic

and body cleaning purposes.

!

The arm of the shower head is intended only to hold

the shower head. Do not load it down with other

objects!

!

Children as well as adults with physical, mental and/

or sensoric impairments must not use this product

without proper supervision. Persons under the

inﬂuence of alcohol or drugs are prohibited from

using this product.

!

Do not allow the streams of the shower touch sensitive

body parts (such as your eyes). An adequate distance

must be kept between the shower and you.

Installation Instructions

• Prior to installation, inspect the product for transport

damages. After it has been installed, no transport or

surface damage will be honoured.

• The pipes and the ﬁxture must be installed, ﬂushed

and tested as per the applicable standards.

• The plumbing codes applicable in the respective

countries must be observed.

• During installation of the product by qualiﬁed trained

personnel, make sure that the entire fastening surface

is even and smooth (no protruding seams or tile

oﬀset), that the ﬁnish of the wall is suitable to apply

the product and has no weak points.

Technical Data

Operating pressure: max. 0,6 MPa

Recommended operating pressure: 0,16 - 0,4 MPa

Hot water temperature: max. 60°C

Thermal disinfection: 70°C / 4 min

The product is exclusively designed for drinking water!

Symbol description

Do not use silicone containing acetic acid!

Dimensions (see page 38)

Flow diagram (see page 38)

Spare parts (see page 44)

XX = Colors

00 = Chrome Plated

14 = Brushed Bronze

34 = Brushed Black Chrome

67 = Matt Black

70 = Matt White

95 = Brushed Brass

99 = Polished Gold-Optic

Cleaning (see page 39)

Test certiﬁcate (see page 44)
