4
English
Assembly (see page 33)
Safety Notes
Gloves should be worn during installation to prevent
crushing and cutting injuries.
With water heaters of 5 liters the flow rate at the
mixer should not exceed 5 l/min. In this case the
flow rate must be reduced at the isolation valve.
Installation Instructions
• Prior to installation, inspect the product for transport
damages. After it has been installed, no transport or
surface damage will be honoured.
• The pipes and the fixture must be installed, flushed
and tested as per the applicable standards.
• The plumbing codes applicable in the respective
countries must be observed.
• The drain valve must only be used as intended. It is
not allowed to attach other objects to the drain
valve, for example a semi-pedestal.
• If necessary shorten platic hose according to the
table and insert it up to the collar into the shorter
blue marked copper pipe.
Technical Data
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,1 - 0,5 MPa
Test pressure: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
Hot water temperature: max. 70°C
Recommended hot water temp.: 65°C
Rate of flow: max. 5 l/min
Thermal disinfection: max. 70°C ⁄ 4 min
The product is exclusively designed for drinking water!
Symbol description
Do not use silicone containing acetic acid!
Dimensions (see page 32)
Spare parts (see page 35)
When changing the spray former, it is imperative to use
one made for this type of mixer.
Cleaning (see page 36)
Operation (see page 34)
• Hansgrohe recommends not to use as drinking water
the first half liter of water drawn in the morning or
after a prolonged period of non-use.
• When the storage tank is being heated, the spout
will drip.
Test certificate (see page 32)
Table for the throttle hose lengths to be used
Highest possible water pressure at
user's site in Mpa
Device content
8, 10 and 15 liters up to 5 liters
0,1 - 0,15 without throttle hose Throttle hose shortened to 90 mm
0,2 - 0,3 Throttle hose shortened to 90 mm Throttle hose unchanged
0,4 - 0,7 Throttle hose unchanged
Adjust flow volume at corner valve
If the water pressure is greater than 0,5 MPa, fit a pressure reducing valve.
Fault Cause Remedy
Insufficient water - Spray former calcified, dirty - Clean spray former, exchanging if
necessary
Mixer stiff - Cartridge defective, calcified - Exchange cartridge
Mixer dripping constantly with water
heater switched off
- Cartridge defective - Exchange cartridge
