Care and maintenancePage EN-22

(6)

(7)

(8)

5. Place the grease filters (8) with the pins

into the openings.

6. Push the locks (7) down; snap the grease

filters (8) in and release the locks.

7. Close the cover (6) again and allow it to

click into place.

8. Switch the power back on.

Inserting/replacing activated

charcoal filters

The activated coal filters remove odours.

They have to be replaced as soon as the

cooking odours can no longer be adequately

filtered. If used frequently, the filters should be

renewed regularly or at least checked every 6

months. For the source of supply, please see

chapter “Service” see Page EN-25.

1. Unplug the mains plug or switch off the

corresponding circuit.

(6)

(7)

(8)

2. Flip the cover (6) up.

3. Open the lock (7) on the grease filter (8)

and carefully pull the grease filter (8)

downwards to remove it.

4. Only when replacing the charcoal filters:

The two activated charcoal filters (9) are lo-

cated to the right and left of the motor (10).

Loosen the two activated charcoal filters

and remove them.

close close

(9)

(10)

5. Place the new activated charcoal filters

to the right and left of the motor (10) and

tighten them in an anti-clockwise direction.

Allow the locks to click into place.
