Preparations for assemblyPage EN-10

Connection for power supply

WARNING

Risk of electric shock!

■ The mains plug must be as accessib-

le as possible during use, i.e. the plug

must be accessible even after the

exhaust hood has been installed.

■ If the mains plug is no longer acces-

sible after installation, an all-poles

disconnecting device complying with

overvoltage category III must be

connected to the house wiring with a

contact gap of at least 3 mm; this in-

cludes fuses, circuit breakers and con-

tactors.

■ Electrical installation may be perfor-

med only by a certiﬁ ed specialist. If

an additional socket is required, have

an electrician perform the installati-

on.

■ Do not connect to a power strip, mul-

tiple socket outlet, timer or to a sepa-

rate remote-controlled system for dis-

tance monitoring and control.

To ensure that the exhaust hood will perform

optimally and that no obtrusive cabling is vis-

ible, plan the connection for power supply

carefully before installation: The exhaust hood

must be placed over the centre of the cooking

zone.

Preparations for assembly

For exhaust air operation

WARNING

Risk of suffocation/explosion!

■ Never attach the exhaust hood to a

ventilation shaft, chimney or smo-

kestack! The air being extracted must

not travel through a channel in which

warm air circulates. The extracted air

may only be released to the outside

through a separate air channel inten-

ded exclusively for the exhaust hood.

NOTICE

Risk of damage to property!

■ We recommend having a specialist

carry out all preparations.

Before you can begin assembly, all of the fol-

lowing conditions must be met:

– There must be a wall or ceiling break of at

least 15.5 cm in diameter.

– If the exhaust air hose passes through an

exterior wall, the air outlet on the outside

must have a cover with self-opening slits

(not included in the package contents).

To keep subsequent energy usage as low as

possible, we recommend

– placing the exhaust air channels as straight

as possible and avoiding any sharp angles

(curves or bends are preferable).

Each bend increases energy usage.

– not reducing the cross-section of the fan

connector. The wider the diameter of the

exhaust air hose and the smoother its inte-

rior surface, the better the extraction func-

tion will be.

– selecting a ventilation conduit with exterior

shutters that can open completely during

use.
