Start-up
Page EN-29
(29)
(28)
(30)
5. Loosen the screws (28) on the middle
hinge (29) and remove the middle hinge.
Retain the two washers (30).
6. Remove the freezer door (6) and set it
aside.
7. Tilt the appliance so that the lower
hinge (32) can be accessed using the
cross-tip screwdriver or the size 8 span-
ner.
(32)
(7)
(31)
8. Loosen the screws (31) on the low-
er hinge (32), unscrew the right screw
foot (7), and remove the hinge.
(7)
9. Screw the screw foot (7) back in.
(33)
10. Loosen the screw (33) and place it back
on the opposite side.
Preparing the hinges
(27)
(34)
1. Unscrew the hinge bolt (34) of the upper
hinge (27) (ideally using a pair of pliers)
and screw it back in on the opposite side.
(36)
(37)
(35)
(32)
2. Use the size 10 spanner and a pair of
pliers to loosen the nut (36) of the hinge
bolt (35) on the lower hinge (32), and
then remove it together with the retaining
ring (37).
