User’s Manual
9
MAKING CONNECTIONS
CONNECTING TO A PC
Turn off your computer before performing the procedure below.
1. Connect one end of the VGA cable to the back of the monitor and connect the other end to the
computer’s VGA port.
2. Connect one end of the HDMI cable to the back of the monitor and connect the other end to the
computer’s HDMI port.
3. Connect the audio cable between the monitor's audio input and the PC's audio output (green port).
4. Connect one end of the USB cable to the back of the monitor and connect the other end to the
computer’s USB port.
5. Plug one end of the 12V DC adapter to the LCD monitor’s DC 12V input socket, plug one end of
the AC power cord to the 12V DC adapter AC input socket, and the other end of the AC power
cord to Wall outlet.
6. Turn on your monitor and computer.
NOTE:
Figure.2. Connecting to a PC
1 2
3
5
7 8
9
4
6
USB OUTUSB IN Type-C
DP
Power DC 12V Input Earphone
VGA Input
DP
USB
LINE IN
HDMI Input
Type-C Input
USB-Type A to B
The HT240CUA is available with USB connection. It is Microsoft Windows 8 HID (Human Inter-
face Device) compatible if you use the USB touch screen interference. No additional software driver
is required. Calibration is a simple process and can be invoked by running Tablet PC Settings from
Control Panel and clicking the Calibrate button.
