Installation Instructions: List of Materials
Required Tools for Installation
Supplied with Unit
Supplied by Installer
• 17mm, 22mm, 26mm or Adjustable Wrench
• #2 Phillips Screwdriver
• Drill
• R-410A Approved Flaring Tool
• Hex Wrench
• Hole Saw 2 1/4”
• Level
• Manifold Gauge
• Measuring Tape
• Micron Gauge
• Mini-Split Adapter (5/16”F to 1/4”M)
• Nitrogen*
• Pipe Cutter
• Razor Knife
• Reamer
• Sealant, non-expanding (for line set opening)
• HVAC leak solution or refrigerant leak detector
• Stud Finder
• Torque Wrench and Back-up Wrench
• Vacuum Pump
• Wire Strippers
• Refrigerant Scale
• Usual and customary HVAC hand tools
• Condensate connecting tube
• Clamp
• Flare nuts (2)
• Insulation
• Refrigerant Line Insulation
• 14/4 (14 gauge – 4 conductor) SOOW cable
• 1 and 1/4 inch PVC for condensate
• Insulation for condensate drain
• 3/8 threaded rod, washers and nuts
• R410A Refrigerant
Copper Refrigerant Line Set
Model Liquid (inch) Vapor (inch)
USYM07UCDDA 1/4 3/8
USYM09UCDSA 1/4 3/8
USYM12UCDSA 1/4 3/8
USYM18UCDSA 1/4 1/2
USYM24UCDSA 3/8 5/8
NOTE: A wired controller is required and must be ordered separately
