1919
• the hose is replaced at the printed due date or if it shows signs of wear or damage, and
replaced regardless of its condition after a maximum of three years.
• you inform the customer that the gas cylinder valve or the gas supply valve immediately
by the cooker should be closed when the cooker is not in use.
• you inform the customer that the hose should not be subjected to corrosion by acidic
cleaning agents.
After connecting the cooker to the gas supply, make sure that you
• check that the connections are correctly sealed using a soapy solution, but never a
naked ame.
• check whether the injectors are correct for the type of gas being used. If not, follow the
instructions under “GAS MAINTENANCE”.
• replace the sealing washer/s on the slightest sign of deformation or imperfection. The
sealing washer/s is/are the part/s which guarantee/s a good seal in the gas connection.
• use two spanners when tting the hose holder (g. 2.2).
Gas connection with rubber hose holders
Note: if not already tted on the inlet pipe, the hose holders are supplied
with the product in a separate kit; if not supplied with the appliance
they can be purchased by contacting the After-Sales Service.
(Important: to be used ONLY IF PERMITTED by the local applicable regulations)
Manifold
male
pipe tting
Inlet pipe
Hose holder
for LPG
Hose holder
for
Natural gas
Hose clamp
(not supplied)
Hose clamp
(not supplied)
LPG NG
Rubber hose (not supplied)
for LPG connection
Rubber hose (not supplied)
for Natural gas connection
1/2” G cylindrical
(ISO 228-1) male
1/2” G cylindrical
(ISO 228-1) female
1/2” G cylindrical
(ISO 228-1) female
Sealing
washer (#)
Fig. 2.2
(#) If not already tted on the inlet pipe,
it is supplied with the appliance in a
separate kit
This gure is
indicative only.
