EN
31
1) Based on 100 drying cycles of the standard Eco program at full and partial load, and the consumption of
the low-power modes. Actual energy consumption per cycle will depend on how the appliance is used.
2) In case there is a power management system.
3) This program used at full and partial load is the standard drying program to which the information in the
label and the che relates to. This is the program suitable for drying normal wet cotton laundry and it is
the most ecient program in terms of energy consumption for cotton.
4) Class G is the least ecient and Class A is the most ecient.
Additional data
Power supply (refer to rating plate) ‑ voltage / current /
input
(220-240) V/50 Hz/ 2.6 A/ 600W
Permissible ambient temperature 5C to 35°C
Refrigerant R290
Volume 150 g
Product dimensions
A
B
F
E
C
D
PRODUCT DIMENSIONS
A Overall height of product mm 845
B Overall width of product mm 595
C Overall depth of product (To main control board size) mm 640
D Overall depth of product mm 680
E Depth of door open mm 1170
F Minimum door clearance to adjacent wall mm 188
Note: The exact height of your dryer is dependent on how far the feet are extended from the
base of the machine. The space where you install your dryer needs to be at least 40 mm wider
and 20 mm deeper than its dimensions.
13 - Technical data
FRONT VIEW TOP VIEW WALL
