28
12.6 Reversing the door
▶ Before you start, unplug the dryer from the socket.
▶ Handle parts carefully to avoid scratching paint.
▶ Provide a non-scratching work surface for the doors.
▶ Tools you will need: Phillips-head screwdriver.
▶ Once you begin, do not move the cabinet until door reversal is completed.
▶ These instructions are for changing the hinges from the right side to the left side.
If you want to switch them back to the right side, follow these same instructions
and reverse all references from left to right.
1. Remove the door assembly
Open the door. Remove the two screws holding the hinge/ door assembly to the dryer.
&DUHIXOO\VHWWKHKLQJHGRRUDVVHPEO\DVLGH)LJ
2. Remove, rotate and replacethe inner door
Remove the eight stickers and screws securing the inner door to the outer door.
Dismantle the inner door, rotate it 180° and reinstall it into the outer door using
the same eight screws and stickers( F ig. 12-5) .
3. Remove, rotate and replace the door lock & strike plate
Remove the two screws holding the strike plate, and then remove one screw
of the door lock, push down and take out the lock, rotate 180° and install it on the
opposite side using the same 3 screws and strikes( F ig. 12-6) .
4. Rotate and replace the hinge/door assembly
5RWDWHWKHKLQJHGRRUDVVHPEO\DQGVFUHZLWRQWKHGU\HU)LJ
EN
12-Installation
WARNING!
,IWKHVXSSO\FRUGLVGDPDJHGLWPXVWEHUHSODFHGE\WKHVHUYLFHDJHQWVHHZDUUDQW\
FDUGLQRUGHUWRDYRLGDKD]DUG
12-8
12.7 Wash-dryer stack
It is possible to achieve a washer-dryer stack.( F ig. 12-8).
Not every washing machine is suitable for this purpose.
Stacking information, as well as the corresponding
mounting kit are available via your local dealer.
The mounting instructions are supplied with the kit
which thoroughly inform the installation steps.
12.8 Level the dryer
