4 EN
NOTE
1.
2.
3.
2.
3.
4.
5.
4.
PREPARATION
IMPORTANT: Do not apply pressure to the screen display
area which may compromise the integrity of the display.
The manuafacturer’s warranty does not cover user abuse
or improper installations.
IMPORTANT: The stand of the TV must be assembled
prior to usage.
ATTACHING THE STAND
TURNNING ON THE TV
PREPARING YOUR LED TV FOR WALL MOUNTING
We suggest that you keep your TV at least 2.36 inches
(60 mm) from the wall to prevent cable interference.
Before mounting your TV on the wall, you need to
remove the stantand.
For your safety, please use only with a UL listed wall
mount bracket with minimum weight of the TV without
stand.
To attach a wall mount bracket to your TV:
Remove the screws holding your TV to the stand.
Remove the stand from your TV.
Secure the wall mount bracket to the back of your
TV using four screws. Follow the instructions of the
user manual that came with the wall mount bracket
to install.
NOTE
The wall mount bracket are not included.
Ensure that the TV is placed in a position to allow free
flow of air. Do not cover the ventilation openings on the
back cover.
To prevent any unsafe situations, no naked flame sources,
such as lighted candles, should be placed on or in the
vicinity.
Avoid heat, direct sunlight and exposure to rain or water.
The equipment shall not be exposed to dripping or
splashing.
Connect the antenna cable or cable TV cable to the
ANT IN aerial socket on the back of the TV set.
Fix the wall mount screws (M6 x 10mm/4pcs) into
the rear side of the LED TV, using the torque of
8kgf,cm.
Install the stand and place the TV on a solid surface.
1.
Turn the TV on:
Press on the remote control or
POWER button at
the bottom of the TV.
Power:
Plug the cord into a working power outlet.
1.
2.
Place the TV unit face down on a soft and flat surface
(blanket, foam, cloth, etc.) to prevent any damage to
the TV.
Fix the stands to the bottom of the TV with 4 screws.
Min
1m
Remove the cover of the battery compartment.
Insert the 2 batteries (Type AAA 1.5V).
Battery
