INSTALLATIONINSTALLATION
Front panel
REAR AV Connections (SIDE)
-6-
1: Remote control sensor.
2: Indicator LED: RED STANDBY.
3: Key board
3
2
1
≤8m
(
(2) In the boot state - Press the button to shut down.
1) In the standby mode - Press the button to start the TV.
All the terminals are (from left to right):
HDMI1(eARC/ARC), LNB IN, ANT IN, USB, CI, EARPHONE output.
All the terminals are (from left to right):
LAN, OPTICAL output, VIDEO, AUDIO input(L/R), HDMI4, HDMI3, HDMI2.
REAR AV Connections
Note:
When HDMI port get DVI signal, the audio signal receives from the AV Audio channel.
400mA
