US07MB2BEA US09MB2BEA US12MB2BEA US18MB2BEA US24MB2BEA
Rated Cooling Capacity Btu/hr 7,000 9,000 12,000 18,000 24,000
Voltage, Cycle, Phase V/Hz/Phase 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1 208-230/60/1
Fan Speed Stages 5 + Auto 5 + Auto 5 + Auto 5 + Auto 5 + Auto
Motor Speed RPM: Cooling
(Turbo/High/Med/Low/Quiet)
830/780/700/640/560 880/800/720/640/560 950/870/780/680/600 880/820/760/700/640 1070/1030/880/790/740
Motor Speed RPM: Heating
(Turbo/High/Med/Low/Quiet)
830/780/700/640/560 880/800/720/640/560 950/870/780/680/600 880/820/760/700/640 1070/1030/880/790/740
Airow CFM: Cooling
(Turbo/High/Med/Low/Quiet)
335/272/190/150/141 353/286/200/150/141 409/350/308/158/148 620/517/332/214/203 927/844/667/564/482
Airow CFM: Heating
(Turbo/High/Med/Low/Quiet)
335/272/190/150/141 358/292/208/155/145 412/355/311/163/152 627/523/337/217/205 927/844/667/564/482
Indoor Sound Level dB: Cooling
(Turbo/High/Med/Low/Quiet)
42/39/37/35/32 44/41/38/35/32 47/44/41/38/35 48/45/42/39/36 47/46/41/38/37
Indoor Sound Level dB: Heating
(Turbo/High/Med/Low/Quiet)
42/39/37/35/32 44/41/38/35/32 47/44/41/38/35 48/45/42/39/36 46/45/40/38/36
Dimension: HxWxD in (mm)
9 3/4 x 31 3/4 x 27 1/2
(248 x 805 x 700)
9 3/4 x 31 3/4 x 27 1/2
(248 x 805 x 700)
9 3/4 x 31 3/4 x 27 1/2
(248 x 805 x 700)
9 3/4 x 47 1/2 x 27 1/2
(248 x 1207 x 700)
9 3/4 x 47 1/2 x 27 1/2
(248 x 1207 x 700)
Weight (Net/Ship)- lbs (kg) 62.17/86.86 (28.2/39.4) 62.17/86.86 (28.2/39.4) 62.17/86.86 (28.2/39.4) 87.74/123.46 (39.8/56) 87.74/123.46 (39.8/56)
Max. External Static Pressure in.W.G (Pa) 0.6 (150) 0.6 (150) 0.6 (150) 0.6 (150) 0.6 (150)
Liquid Pipe O.D. (in) 1/4 1/4 1/4 1/4 3/8
Suction Pipe O.D. (in) 3/8 3/8 3/8 1/2 5/8
Drainpipe Size 1* 1* 1* 1* 1*
Condensate Pump Built-In Yes Yes Yes Yes Yes
Max. Drain-Lift Height in(mm) 27 1/2 (700) 27 1/2 (700) 27 1/2 (700) 27 1/2 (700) 27 1/2 (700)
WiFi**
Built-in Built-in Built-in Built-in Built-in
Factory-Installed Refrigerant Detection
Sensor (RDS)
Yes Yes Yes Yes Yes
*Condensate drain adapter shipped with the indoor unit is designed to accept a 3/4” PVC pipe.
MID-STATIC DUCTED
WARM START
Ensures the fan does not blow cold air during heating
mode startup.
TURBO MODE
Delivers rapid cooling or heating, making it ideal for
quickly adjusting the room temperature.
COMPACT DESIGN
Less than 10” height saves ceiling space.
CONDENSATE PUMP
Factory-installed condensate pump.
0.6” EXTERNAL STATIC
Designed for static pressure up to 0.6” w.g.
AUXILIARY HEATER COMPATIBLE
Compatible with many third-party auxiliary heaters.
FRESH AIR KNOCKOUT
Unit designed with a 4” round fresh air knockout.
OPTIONAL ACCESSORIES
MERV lter box and supply plenums available (sold
separately) for easy installation.
Multi-Zone
Indoor Unit Specications
**WiFi includes SmartHQ
TM
Home and SmartHQ
TM
Service compatibility.
