31-5001099 Rev. 1 25
Installation Instructions
Step 1 - Preparation
A. Before installing the indoor unit, determine if a refrigerant leak sensor is required.
Refer to the outdoor unit installation instructions for calculating the total refrigerant charge. Measure the area of the
space that will be conditioned by the indoor unit, and refer to the below table :
If your room size is smaller than the minimum room size listed above, a refrigerant leak sensor may be required. See
below table:
Installation in rooms smaller than the minimum sizes listed above are not allowed based on the standard of UL60335-
2-40 Edition 4².
1: Calculated based on a minimum install height of 7 ft 2-3/4 inches (2.2m) measured from the floor to the bottom of
the indoor unit.
2: UL60335-2-40 Edition 4 has been adopted by majority of state and local codes. A limited number of
local and state codes may require compliance to UL 60335-2-40 Edition 3. Please refer to our website at
GEAppliancesAirandWater.com for guidance on installations in those localities.
Note: Additional room area may be needed for different installation altitudes. Please use Altitude Adjustment Factor
table below by multiplying minimum room size by the altitude adjustment factor based on install altitude.
B. If leak sensor is not needed, make sure to flip dip switch 1-5 to ON.
Missing this step will result getting error code bA.
If leak sensor is needed, please go to step C.
Compact Cassette without Refrigerant Leak Sensor Installed¹
Maximum Refrigerant
Charge
lbs 3.9 4 4.5 5 5.5 6 6.5 7 7.5 8 8.5 9
oz 62.4 64 72 80 88 96 104 112 120 128 136 144
Minimum Room Size ft² No restriction 59 67 74 82 89 97 104 112 119 127 134
Compact Cassette with Refrigerant Leak Sensor Field-Installed¹
Maximum Charge
lbs 3.9 4 4.5 5 5.5 6 6.5 7 7.5 8 8.5 9
oz 62.4 64 72 80 88 96 104 112 120 128 136 144
Minimum Room Size ft² No restriction 60 68 75 83 90 98 105 113 120 128 135
Altitude (m) 0 200 400 600 800 1000 1200 1400 1600
Altitude (ft) 0 660 1310 1970 2620 3280 3940 4590 5250
Adj. Factor 1 1 1 1 1.02 1.05 1.04 1.1 1.12
Altitude (m) 1600 1800 2000 2200 2400 2600 2800 3000 3200
Altitude (ft) 5250 5910 6560 7220 7870 8530 9190 9810 10500
Adj. Factor 1.12 1.15 1.18 1.21 1.25 1.28 1.32 1.36 1.4
Altitude Adjustment Factor
