Ducted, Console Compatibility
*
l =Standard Controller.
¡= Optional Controller.
¤= Optional Controller requires WK-B adapter.
Remote controllers WJ01X24721 and WJ26X27153 are shipped with indoor unit.
Ducted units do not include controller. A controller must be ordered separately.
Cassette does not ship with controller. Panel must be purchased separately and ships with controller.
Indoor/Outdoor Compatibility Charts
Quick Reference Guide
Outdoor
1U24LP2HDA 1U3036LP2HDA 1U3036LP2HDA 1U4248LP2HDA 1U4248LP2HDA
Indoor
USYL24UCDDA USYL30UCDDA USYL36UCDDA USYL42UCDDA USYL48UCDDA
Line Size: Liquid (Suction) in.
3/8 (5/8) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4)
IDU Flare Size: Liquid (Suction) in. 3/8 (5/8) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4)
ODU Port Size: Liquid (Suction) in. 3/8 (5/8) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4)
Lineset Adapter Required None None None None None
Large Cassette Systems
Compact Cassette Systems
Outdoor
1U09EH2HEB 1U12EH2HEB 1U18EH2HEB
Indoor
AB09SC2VHA AB12SC2VHA AB18SC2VHA
Line Size: Liquid (Suction) in.
1/4 (3/8) 1/4 (3/8) 1/4 (1/2)
IDU Flare Size: Liquid (Suction) in. 1/4 (3/8) 1/4 (3/8) 1/4 (1/2)
ODU Port Size: Liquid (Suction) in. 1/4 (1/2) 1/4 (1/2) 1/4 (1/2)
Lineset Adapter Required 1/2 to 3/8* 1/2 to 3/8* None
Console Systems
Outdoor
1U09EH2HEB 1U12EH2HEB 1U18EH2HEB
Indoor
USYF09UCDWA USYF12UCDWA USYF18UCDWA
Line Size: Liquid (Suction) in.
1/4 (3/8) 1/4 (3/8) 1/4 (1/2)
IDU Flare Size: Liquid (Suction) in. 1/4 (3/8) 1/4 (3/8) 1/4 (1/2)
ODU Port Size: Liquid (Suction) in. 1/4 (1/2) 1/4 (1/2) 1/4 (1/2)
Lineset Adapter Required 1/2 to 3/8* 1/2 to 3/8* None
Outdoor
1U09EH2HEB 1U12EH2HEB 1U18EH2HEB 1U24LP2HDA 1U3036LP2HDA 1U3036LP2HDA
Indoor
AW09EH2HEB AW12EH2HEB AW18EH2HEB AW24TL2HFA AW30TL2HFA AW36TL2HFA
Line Size: Liquid (Suction) in.
1/4 (1/2) 1/4 (1/2) 1/4 (1/2) 3/8 (5/8) 3/8 (5/8) 3/8 (5/8)
IDU Flare Size: Liquid (Suction) in. 1/4 (1/2) 1/4 (1/2) 1/4 (1/2) 3/8 (5/8) 3/8 (5/8) 3/8 (5/8)
ODU Port Size: Liquid (Suction) in. 1/4 (1/2) 1/4 (1/2) 1/4 (1/2) 3/8 (5/8) 3/8 (3/4) 3/8 (3/4)
Lineset Adapter Required None None None None 3/4 to 5/8* 3/4 to 5/8*
Highwall Systems
Outdoor 1U09EH2HEB 1U12EH2HEB 1U18EH2HEB 1U24LP2HDA 1U3036LP2HDA 1U3036LP2HDA 1U4248LP2HDA 1U4248LP2HDA
Indoor USYM09UCDSA USYM12UCDSA USYM18UCDSA USYM24UCDDA USYM30UCDDA USYM36UCDDA USYM42UCDDA USYM48UCDDA
Line Size: Liquid (Suction) in.
1/4 (3/8) 1/4 (3/8) 1/4 (1/2) 3/8 (5/8) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4)
IDU Flare Size: Liquid (Suction) in. 1/4 (3/8) 1/4 (3/8) 1/4 (1/2) 3/8 (5/8) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4)
ODU Port Size: Liquid (Suction) in. 1/4 (1/2) 1/4 (1/2) 1/4 (1/2) 3/8 (5/8) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4) 3/8 (3/4)
Lineset Adapter Required 1/2 to 3/8* 1/2 to 3/8* None None None None None None
Ducted Systems
Arctic Single Zone Piping Specications and Adapter Requirements
*Adapter shipped with outdoor unit. Install on outdoor unit.
OUTDOOR UNITS CONTROLLERS*
TEMPO
ADVANCED
PLUS
ARCTIC
ARCTIC
MULTI
FLEXFIT
MULTI
WJ01X24721
WJ26X27153
YR-HBS01
UCT30RWA
YR-E16B
YR-E17
QACT17A
1U09TE1VHA
1U12TE1VHA
1U09TE2VHA
1U09TE2HDA
1U12TE2VHA
1U12TE2HDA
1U18TE2HDA
1U24TE2HDA
1U24TL2HFA
1U3036TL2HFA
1U09AP2HDB
1U12AP2HDB
1U15AP2HDB
1U18AP2HDB
1U24AP2HDB
1U09EH2HEB
1U12EH2HEB
1U18EH2HEB
1U24LP2HDA
1U3036LP2HDA
1U4248LP2HDA
2U20EH2HDA
3U24EH2HDA
4U36EH2HDA
2U18MS2HDA
3U24MS2HDA
4U36MS2HDA
5U42MS2HDA
INDOOR DUCTED UNITS
USYM09UCDSA
ü ü ü ü ü ü ü ü
¡ ¡ ¡
USYM12UCDSA
ü ü ü ü ü ü ü ü
¡ ¡ ¡
USYM18UCDSA
ü ü ü ü ü ü
¡ ¡ ¡
USYM24UCDSA
ü ü ü
¡ ¡ ¡
USYM24UCDDA
ü
¡ ¡ ¡
USYM30UCDDA
ü
¡ ¡ ¡
USYM36UCDDA
ü
¡ ¡ ¡
USYM42UCDDA
ü
¡ ¡ ¡
USYM48UCDDA
ü
¡ ¡ ¡
INDOOR CONSOLE UNITS
USYF09UCDWA
ü ü ü ü ü ü ü ü
l ¡ ¡ ¡ ¡
USYF12UCDWA
ü ü ü ü ü ü ü ü
l ¡ ¡ ¡ ¡
USYF18UCDWA
ü ü ü ü ü ü
l ¡ ¡ ¡ ¡
