14 31-5001082 Rev. 2
ENGLISH
Required Tools for Installation
• 5/8” (16mm), 7/8” (22mm), 1” (25mm) or Adjustable
Wrench
• Adhesive tape*
• Conduit cable clamp 1/2”*
• #2 phillips screwdriver
• Drill
• R454b flaring tool
• Hex wrench
• Hole saw 2 1/4”
• Insulation*
• Refrigerant scale
• Level
• Manifold gauge set
• Measuring tape
• Micron gauge
• Mini-split adapter (5/16”F to 1/4”M)
• Nitrogen*
• Pipe cutter
• PVC pipe
• Razor knife
• Reamer
• Saddle clamp (L.S.) w/ screws
• Sealant, non-expanding (for lineset hole)
• Soap/water solution* or gas leakage detector
• Stud finder
• Torque wrench
• Vacuum pump
• Wire strippers
• All usual and customary HVAC hand and power tools,
meters, and testing devices
* consumable
INSTALLATION INSTRUCTIONS
Supplied by Installer
Refrigerant Line Set: for sizing please refer to the Outdoor Unit Rating Plate
• 14/4 AWG SOOW Non-Shielded Stranded Copper Cable
• R454B Refrigerant (if extra charge is needed, see next section)
• Refrigerant line insulation
• PVC Pipe (optional)
• Condensate drain tubing clamp
• 16/2 AWG Shielded Stranded SOOW Cable for high speed communication
• Hardware for securing outdoor unit to base
• Unit stand & base
• Mounting hardware to stand
- Suggestion: M10*30 (bolt diameter is M10; bolt length is 30 mm)
• Power supply cord
• Electrical disconnect
• Electrical breaker
