31-5001078 Rev. 0 19
ENGLISH
INSTALLATION INSTRUCTIONS
G. Refrigerant Charging
• Add any additional refrigerant after evacuation using a digital scale.
NOTE: Charge liquid only.
• Fill out the refrigerant charge label using indelible ink.
• Place the factory refrigerant charge found on the outdoor nameplate in box number 1.
• Place the amount of additional refrigerant added in box number 2.
• Add boxes 1 and 2 together and place the value in the sum box (D).
• Adhere the filled out label in the proximity of the product charging port and under the outside unit valve cover.
• Write amounts on outdoor unit with permanent marker above the charging port if the label is missing.
• Remove the cap from the liquid line valve. Using a hex wrench, open the valve, then replace and tighten the cap securely
to avoid leaks.
• Remove the cap from the suction line valve. Using a hex wrench, open the valve, then replace and tighten the cap
securely to avoid leaks.
• Wrap the line set, drain line, and 14/4 AWG wiring starting at the bottom of the bundle with an overlap type wrap until
you reach the piping hole.
• Use a sealant to seal the piping on both sides of the wall in order to prevent drafts, weather, or pests from entering the
building.
Step 4 - Final Check
Check Items for Test Run
No gas leak from linesets?
Are the linesets insulated properly?
Are the connecting wirings of indoor and outdoor
firmly inserted to the terminal block?
Is the connecting wiring of indoor and outdoor fixed?
Is condensate draining correctly?
Is the ground wire securely connected? Is the indoor
unit securely fixed?
Is power source voltage correct according to local
code?
Is there any odd noise?
Does the cooling temperature drop between
20-30°F?
Does the heating temperature raise between
35-40°F?
Is the room temperature display accurate?
Explaining Operation To the End User
• Using the User Manual, explain to the user how to use
the air conditioner/heat pump, (the remote controller,
adding/removing the air filters, placing or removing
the remote controller from the remote control holder,
cleaning methods, precautions for operation, etc.).
• Review precautions for operation.
• Recommend that the user read the Operating
Instructions carefully.
UACT32A Central Controller (Optional
Accessory)
If installing a central controller, use RS485
communication compliant 16/2 AWG shielded SOOW
wire and connect the wiring to terminals C1 and C2 on
the outdoor unit terminal block. See section C of Step
3 in this manual for the location of C1 and C2 on the
terminal block.
