6LE008220A
Floor installation systems
FAQ
Page 16/61
Floor installation systems
Answer 7: Which installation units are required?
Supply and installation units
To supply commercial buildings in a sensible manner, it is wise not to cut corners - with regards
to both energy and also information and data. The electraplan supply and installation units. VE-
EEs can cover any customer requirements.
They are compatible with almost any electraplan floor installation system and can be equipped
with six to twelve connector boxes, according to requirements. The supply units are available in
a range of materials, shapes and colours.
Each device casing can be equipped variably: With protective contact sockets or support bar
devices for network and multimedia technology.
Polyamide supply unit
The standard material for supply units is polyamide. Poly-
amide frames can withstand a load of up to 1.5 kN (DIN
specification) - ideal for classic floor use. Large selection for
use with 6, 9, 10 or 12 sockets, for example:
Aluminium supply unit
In conjunction with high-quality floor coverings - e.g. stone
tiles - it is wise to use aluminium supply units. They are not
only more stable, but also provide a more elegant floor
appearance. Hager can offer aluminium units that can
withstand loads of up to 7.5 kN for strong loads in public
buildings - e.g. showrooms, stations or airports. Sizes: 2
sizes for use with 6 or 12 sockets, for example.
Stainless steel supply units
Stainless steel supply units are particular robust:
They correspond to the DIN load specifications of 1.5 kN.
As a heavy duty cassette, they can even withstand loads
of up to 20 kN (see Page 48). A further advantage: Thanks
to their thin edge, they are barely noticeable in the floor - if
they are, then its due to their fine appearance.
Sizes: 2 sizes for use with 6 or 12 sockets, for example.
