6LE008221A
Floor installation systems
Basic manual
Page 37/61
Floor installation systems
Stainless steel cassette EKQ/EKR/EKSQ/EKSR
The cassettes can be levelled to be flush with the height of the floor and can be completely
decoupled from the socket base. Cassettes are particularly suitable for floor coverings like tiles
or parquet. Various versions are available for dry/moist and wet cleaned floor coverings. The
stainless steel cassettes offer continuous quality and also look attractive.
Levellable stainless steel cassettes for dry or moist cleaned floors are available in two versions.
The minimum installation depth from the top edge of the finished floor is 100 mm for the blank
stainless steel cassette and between 105 and 115 mm for stainless steel cassettes with device
casing. The device casings can be lowered in stages down to 18 mm and a mounting device for
a locking extension is possible.
Stainless steel cassette EKQ/EKR/EKSQ/EKSR
Forms
Nominal sizes Q12, R12, Q06, R06,
Number of socket
outlets
12.6
Floor covering depth 23 mm, 38 mm
Version Blank, cable outlet, cone
Minimum installation
depth
100 mm, 105 mm, 115 mm
Material Stainless steel
Colours Stainless steel
Table 7: Overview of stainless steel cassettes
