Order number system
Device casings - installation devices - Schuko power sockets
Identifier Type Type
Accessory/shielding
Orientation/degrees Colour
E = Installation de-
vices
W
S = Schuko power socket
D = Data module
U = Surge protection
MR01 = Blank plate for
Rastec 45, single
MR02 = Blank plate for
Rastec 45, double
X
R1 = Rastec 45, single
R2 = Rastec 45, double
R3 = Rastec 45, triple
S = shielded
U = unshielded
S315 = 3 connecting lines
1.5 mm²
S615 = 6 connecting lines
1.5 mm²
Y
20 = 20 degrees
33 = 33 degrees
RJ45 = RJ45
Z
9010 = RAL 9010, pure white
2004 = RAL 2004, pure orange
3000 = RAL 3000, blazing red
6001 = RAL 6001, emerald green
6029 = RAL 6029, mint green
C6A = Cat.6A
9010 = RAL 9010, pure white
Device casings installation devices - Device casings for data equipment
Identifier Accessories Type
Accessories
Type Number of openings
GT = device carriers W
V = for service unit
X
D = data equipment
DM = Data equipment
mounting plate
Y
200 = for installation of
2 mounting plates
300 = for installation of
3 mounting plates
00B = Blank
RJ45
01 x 19.3 x 14.8
02 x 20.4 x 27.7
03 = 19.5/21.7 x 14.85
04 x 17.2 x 18.3
05 x 20.1 x 14.8
06 x 18 x 22.8
07 x 21.7 x 22.4
08 x 20.1 x 19.5
09 x 25.2 x 25.2
Optical fibres
20 x 9.8 x 8
21 x 9.7 x 13.3
22 x 9.7 x 26
Audio/video
30 = 12.8 x 21 - D-Sub 9
31 = diameter 24 - XLR
33 = 25 x 39 - Kindermann
Z
1 = one opening
2 = two openings
3 = three openings
4 = four openings
Mounting panels and CEE power socket
Identifier Type Type
Accessories
Type
GB = device casings
E = Installation
device
X
V = for service unit
CEE = CEE
Y
C = CEE mounting
panel
16 = 16 A
32 = 32 A
Z
300 = replaces GBVR300, GTVR300, GTVD200
400 = replaces GBVR400, GTVR400, GTVD300
5 = 5-pole
