224 Technical adaptations possible
electraplan.GB-EG
Properties:
- Data module Rutenbeck UMflex-real. Cat.6a in shielded (S) and
on shielded versions (U)
- Can be used in connection with mounting plate GTVDM013 in
device carrier GTVD300 or GTVD200
EDSRJ45C6A
Data module RJ45 Cat.6a
Designation PU Order no.
Data module Cat.6a shielded 1 EDSRJ45C6A
Data module Cat.6a unshielded 1 EDURJ45C6A
electraplan.GB-EG
Device carriers for data equipment and mounting plates
Properties:
- Device carrier for service units VQ12, VR12 or VR10
(centre)
- Accepts 3 mounting plates for data or media equipment
- Dimensions: 46 x 75 x 225 mm (H x W x L)
- Assembly type: snap-in, with latch
- Minimum installation depth: 70 mm with 5 mm flooring
recess in the cover of the service unit
- Minimum installation depth: 77 mm with 12 mm flooring
recess in the cover of the service unit
- Material: PC/ABS, halogen-free
- Delivery colour: RAL 9011, graphite black
GTVD300
Device carrier for 3 mounting plates for data equipment
Designation PU Order no.
Device carrier f. 3 mount. pl. f. data equ. 1 GTVD300
Properties:
- Device carrier for service unit VQ06, VR06 or VR10
(left and right)
- Accepts 2 mounting plates for data or media equipment
- Dimensions: 46 x 75 x 171 mm (H x W x L)
- Assembly type: snap-in, with latch
- Minimum installation depth: 70 mm with 5 mm flooring
recess in the cover of the service unit
- Minimum installation depth: 77 mm with 12 mm flooring
recess in the cover of the service unit
- Material: PC/ABS, halogen-free
- Delivery colour: RAL 9011, graphite black
GTVD200
Device carrier for 2 mounting plates for data equipment
Designation PU Order no.
Device carrier f. 2 mount. pl. f. data equ. 1 GTVD200
Properties:
- Mounting plate, double, metal, for data equipment with installation
opening: 19.3 x 14.8 mm, e.g. Rutenbeck
Mounting plate
Designation PU Order no.
Mounting plate GTVD2/300 2xRJ45 19,3x14,8 1 GTVDM012
Properties:
- Mounting plate, triple, metal, for data equipment with installation
opening: 19.3 x 14.8 mm, e.g. Rutenbeck
GTVDM013
Mounting plate
Designation PU Order no.
Mounting plate GTVD2/300 3xRJ45 19,3x14,8 1 GTVDM013
GTVDM012
