180 Technical changes reserved
electraplan.VE-EE
electraplan.VE-EE
Hinged cover and blank cover for ultra-flat installation depth
Designation PU Order no.
Mounting plate for adapter RJ45 19.3x14.8 mm 1 GBVDM012
GBVDM012
Mounting plate for adapter frame, data equipment
Properties:
for accommodating data equipment from following manufacturers and modules:
- Setec SeSix Keystone Jack RJ45 Cat.6
- Telegärtner AMJ module Cat. 6+
- Rutenbeck UM-real. Cat.6a
- Dätwyler Unilan RJ45 module MS-K 1/8 Cat.6a, Unipatch TERA,
- Dätwyler Unilan RJ45 module KST 1/8 Cat.6a Tool-less
- Brand-Rex snap-in connection module Cat.6
- Brand-Rex Cat6Plus STP module tool-less shielded C6CJAKS000
- Brand-Rex 10GPlus STP module tool-less shielded AC6JAKS000
- R&M connection module RJ45 snap-in
- Nexans LANmark-7 GG45 snap-in socket, LANmark-6 Evo, LANmark-5 Evo
- Kerpen Eline 600 GG45 socket, Variokeystone
- TKM RJ-MOD - Cat.6
- EVN electronic components, media technology
- Quante
- Krone
Designation PU Order no.
Mounting plate for adapter RJ45 19.5x14.8 mm 1 GBVDM032
GBVDM032
Mounting plate for adapter frame, data equipment
Mounting plate for adapter frame, data equipment
for accommodating data equipment from following manufacturers and modules:
- BTR E-DAT module 8(8) Cat.6A
- BTR E-DAT module coupling 90° (or 180°) 8(8) Cat.6
- BTR C6A module K180°
- BTR UAE module 8(8) Cat.5e / Cat.6
- BTR OpDAT module LCMM (or LC SM, or ST SM/MM)
- BTR COAX module F-socket (or IEC socket, or IEC plug)
- BTR Blank module
- Dätwyler Unilan module MS 1/8 Cat.6
- Matching blank cap: BTR order number: 130898-00-I
Designation PU Order no.
Mounting plate for adapter RJ45 21.4x14.8 mm 1 GBVDM052
GBVDM052
Mounting plate for adapter frame, data equipment
Properties:
for accommodating data equipment from following manufacturers and modules:
- AMP SL 110 Connect Jack Cat. 6
- AMP AMP-TWIST-6S SL Jack Cat. 6; AMP-TWIST-6AS SL Jack Cat. 6A
- AMP AMP-TWIST-7AS SL Jack Cat. 7
- Brand Rex: Gigaplus, Cat6Plus and 10GPlus UTP module, unshielded
(GPCJAKUxx, C6CJAKUxx, AC6JAKUxx)
- CobiNet TopKey Keystone Cat.6 RJ45
- Matching blank cap: AMP order number: 0-1116412-1
GBVDMR45
Designation PU Order no.
Adapter frame Rastec 50 on 45 data PA 1 GBVDMR45
Adapter frame for data equipment in Rastec 45
Properties:
- Able to accommodate mounting plates for data modules
