Je bekijkt pagina 11 van 308
9
Technical changes reserved
electraplan.UK
electraplan.UK
Trunking overview
2 compartments
3 compartments
2 compartments
3 compartments
2 compartments
3 compartments
2 compartments
3 compartments
2 compartments
3 compartments
2 compartments
3 compartments
2 compartments
3 compartments
2 compartments
3 compartments
2 compartments
3 compartments
Trunkings Trunking width
mm
Trunking height
mm
Variant Compartment
dimensions
mm
Usable
cross-section
cm²
Max. Line
allocation
Ø 11 mm, half full
Page
UK1900282 190 28 2 compartments 75 / 115 53.2 21 (8 / 13) 10
UK1900283 190 28 3 compartments 60 / 70 / 60 53.2 20 (6 / 8 / 6) 10
UK1900382 190 38 2 compartments 75 / 115 72.2 29 (11 / 18) 10
UK1900383 190 38 3 compartments 60 / 70 / 60 72.2 28 (9 / 10 / 9) 10
UK1900482 190 48 2 compartments 75 / 115 91.2 36 (14 / 22) 10
UK1900483 190 48 3 compartments 60 / 70 / 60 91.2 35 (11 / 13 / 11) 10
UK2400282 240 28 2 compartments 100 / 140 67.2 27 (11 / 16) 12
UK2400283 240 28 3 compartments 85 / 70 / 85 67.2 26 (9 / 8 / 9) 12
UK2400382 240 38 2 compartments 100 / 140 91.2 36 (15 / 21) 12
UK2400383 240 38 3 compartments 85 / 70 / 85 91.2 36 (13 / 10 / 13) 12
UK2400482 240 48 2 compartments 100 / 140 115.2 46 (19 / 27) 12
UK2400483 240 48 3 compartments 85 / 70 / 85 115.2 45 (16 / 13 / 16) 12
UK3400282 340 28 2 compartments 140 / 200 95.2 39 (16 / 23) 14
UK3400283 340 28 3 compartments 115 / 110 / 115 95.2 38 (13 / 12 / 13) 14
UK3400382 340 38 2 compartments 140 / 200 129.2 52 (21 / 31) 14
UK3400383 340 38 3 compartments 115 / 110 / 115 129.2 53 (18 / 17 / 18) 14
UK3400482 340 48 2 compartments 140 / 200 163.2 66 (27 / 39) 14
UK3400483 340 48 3 compartments 115 / 110 / 115 163.2 65 (22 / 21 / 22) 14
