78 Technical changes reserved
electraplan.BK
electraplan.BK
Accessories
BKZSA200
Earth conductor for earthing of the trunking system
Properties:
- Screwed to straight trunking connector, flexible wire 2.5 mm²,
200 mm long, green/yellow
- 1 x ring cable lug, 1 x wire end ferrule
- Suitable for screed-flush trunking systems for dry-cleaned floors
BKZSAK00
Earth conductor, connecting clamp
Properties:
- Connecting terminal with inner profile slot, flexible wire 4 mm²,
200 mm long, green/yellow
- Suitable for screed-flush floor trunking with sealing option
BKZM203
Sponge rubber strip
Properties:
- Sponge rubber strip for absorbing expansion pressure,
self-adhesive, for installation on-site on the side profiles
- 2 metres of sponge rubber required for each metre of trunking
- Always coordinate use of the sponge rubber strips with the screed layer.
BKZBSK7011
Abutting edge for covering
Properties:
- If required
- The abutting edge for the covering can be used visibly
(height 4 mm) or concealed by the floor covering.
- 2 metres of abutting edge for covering required for each
metre of trunking
- Abutting edge for covering with a height of 3.2 mm
available on request
Material:
- PC/ABS halogen-free
Available colours:
- RAL7011, iron grey
- RAL9005, deep black
Designation PU Order no.
Abutting edge for covering height 4 mm PC/ABS hal.-free, eg 1 BKZBSK7011
Abutting edge for covering height 4 mm PC/ABS hal.-free, ts 1 BKZBSK9005
Designation PU Order no.
Earth conductor for earthing of the underfloor trunking 1 BKZSA200
Designation PU Order no.
Erdungsklemme zu Bodenkanal BK 1 BKZSAK00
Designation PU Order no.
Sponge rubber strip, 20 x 3mm, self-adhesive 1 BKZM203
