Je bekijkt pagina 255 van 308
253
Technical adaptations possible
tehalit.DAP|DEP
Room distributors
tehalit.DAP
Capacity
Bending radii
Lines
Power type U
0
<= 0.6/1 kV U
0
>= 0.6/1 kV
Power ratings for fixed Outer line diameter in mm
Routing d <= 10 10< d <= 25 25 < d
Fixed routing 4d 4d 4d 6d
Flexible lines Outer diameter of line in mm
d <= 8 8 < d <= 25 12 < d < 20 20 < d 6d
Fixed routing 3d 3d 4d 4d 10d
Infeed 3d 4d 5d 5d
According to VDE 0298 part 3 (1983) the following bending radii must
be observed for plastic lines:
Standard EN 187101 recommends the following:
R
radius
= 10 x d
cable
with R
bend
= bending radius of cable,
d
cable
= cable diameter
Cable manufacturers may specify deviating bending radii.
Please observe the technical data sheets provided with the
respective products.
Information is subject to change
Optical fibre
Manufacturer Outer diameter Minimum
of line in mm bending radii in mm
Alcatel/Kabelmetal 3.5 - 12 20 - 95
ANT 3.5 - 12 150
Dätwyler 3.0 - 7.9 30 - 120
Kabelreydt 3.4 - 11.6 20 - 175
Belden 2.9 - 13 75 - 130
