Je bekijkt pagina 188 van 308
186
Technical changes reserved
electraplan.VE-EE
electraplan.VE-EE
Order number system
Service units - installation units - power sockets
Service units - Installation units - Pedestal boxes
Identifier Shape Furnishing Colour/material
BS = floor socket X
Q = square / hinged
R = round / hinged
F = wing opening / square
Y
RJ45R45 = RJ45 data socket and
Rastec 45 power socket
Z
E = stainless-steel cast material
B = bronze cast material
Identifier Accessories Type Colour
GBZ = device casing for
pedestal box
X
W = installation wall
KR00 = clamping ring
Y
B = blank
N = standard D
R1 = 1 x Rastec
R2 = 2 x Rastec
C = 1 x CEE
Z
7011 = RAL 7011, iron grey
9005 = RAL 9005, deep black
Identifier Number of installation fields Colour
GBZ = device casing for
pedestal box
Y
2 = two fields, 1 x front, 1 x rear
4 = four fields, 2 x front, 2 x rear
8 = eight fields, 4 x front, 4 x rear
Z
7011 = RAL 7011, iron grey
9005 = RAL 9005, deep black
Service units - installation units - pedestal boxes - accessories
Service units - installation units - hinged cover for ultra-low installation depth
Identifier Shape/number of installation
devices
Flooring cutout / cover inlay -
cardboard
Colour
KD = hinged cover
BD = blank cover
X
Q08 = square for 8 installation
devices
E04 = rectangular for 4 installation
devices
Y
05 = 5 mm flooring cutout
08 = 8 mm flooring cutout
12 = 12 mm flooring cutout
Z
7011 = RAL 7011, iron grey
9005 = RAL 9005, deep black
Service units - installation units - wet-cleaned floors
Identifier Shape/number of instal-
lation devices
Mounting kit Type/colour Colour/material
VAN = service unit, aluminium
(flooring frame), wet-
cleaned floors
W
R12 = round, for up to 12
installation devices
R2 = round, for up to 6 in-
stallation devices
X
00 = with mounting kit for
cavity floors
01 = with mounting kit for
junction boxes
Y
= aluminium, chequered
9005 = RAL 9005, deep black,
grooves in contrasting
colour
03 = for bonding in of 3-mm
flooring
Z
TU = integrated tube
made of poly-
amide
Service units - installation units - device casings
Identifier Type Number of power socket casings /
adapter type
Colour
GB = device casings X
ES = installation device, Schuko
power socket
M = for 2 Mosaic installation de-
vices
MAR = adapter frame for Rastec 50
x 50 to 45 x 45 mm
Y
2 = two power socket casings
5050 = Rastec 50 x 50 mm
5045 = 50 x 50 to 45 x 45 mm
Z
9010 = RAL 9010, pure white
2004 = RAL 2004, pure orange
3000 = RAL 3000, blazing red
