276

Technical changes reserved

Technical

Information

Laying of ﬂooring

Preparation

The screed must be fully cured before installation. Flooring that becomes detached from the screed constitutes a trip hazard.

Use a butt joint cover to eliminate trip hazards. Follow the relevant health and safety guidelines in the workplace that apply in your country.

In Germany, you must ensure compliance with section 4.9 "Safety regulations for office workplaces" of the Administration Professional

Liability Insurers Association. In this case, and if the carpet frays significantly, we recommend the installation of a butt joint cover.

Note: The company laying the flooring is responsible for cutting and laying the flooring accurately at the exit points of the trunking system

(VOB Part C/DIN 18365).

Trunking covers made of wood materials must be treated on both sides, as otherwise the trunking covers may warp.

If flooring is bonded on one side only, we recommend the use of double-sided adhesive carpet tape.

Covering butt edge / connection of flooring at flush floor trunking system:

The blank trunking covers need to be lifted off before the flooring can be laid.

A plastic PVC profile is installed at the factory in the left side and right side profile of the trunking.

The plastic profile can be fitted flush (bonded over) or raised (visible) as a covering butt joint edge.

Flush covering butt joint edge (0 mm protrusion):

This type of installation is recommended if the trunking covers are rarely lifted. This is not suitable for fraying carpets. We recommend using

a butt joint cover. Insert the plastic profile in a flush position inside the trunking side profile and bond it in place. After the bond has cured, lay

the carpet over the trunking and cut off the flooring on the inside of the plastic profile. Do not damage the plastic profile. The cut-off carpet

should be used for covering the blank trunking covers. In the case of hard flooring such as wood or tiles the flooring should be worked up to

the inside of the PVC profile. An appropriate expansion joint must be provided.

Raised covering butt joint edge (4 mm protrusion, also available in 3.2 mm as an option):

This type of installation is recommended if the trunking covers will be lifted frequently. This is not suitable for fraying carpets. We recommend

using a butt joint cover. Remove the plastic profile from the trunking side profile. Lay the carpet over the trunking, cut off the flooring on the

inside of the trunking side profile. The cut-off carpet should be used for covering the blank trunking covers. Insert the plastic profile in the

trunking side profile in a raised position and bond it in place. A PVC flooring can be welded to the butt edge. In the case of hard flooring such

as wood or tiles the flooring should be worked up to the inside of the PVC profile. An appropriate expansion joint must be provided.

Concealed screw heads (rare lifting of trunking covers):

Set clean trunking covers with the countersunk side facing upwards into the trunking and screw in the fastening screws.

Cover and bond each trunking cover with flooring. Take care to observe the direction of the web of the carpet.

(Attention: Before you open the trunking cover, detach the flooring from the trunking cover to gain access to the fastening screws.)

Visible screw heads (frequent lifting of trunking covers):

Bond the flooring to the non-countersunk side of the clean trunking cover.

Take care to observe the direction of the web of the carpet. Place the trunking cover into the trunking. Screw the fastening screws of the

trunking cover through the carpet into the trunking side profile. The web of the carpet covers and conceals the screw heads.

Butt joint cover / connection of flooring to flush floor trunking system:

The use of a butt joint cover is recommended for easily fraying carpet. Items are supplied loose in sections of 2.4 meters. The blank trunking

covers need to be lifted off before the flooring can be laid. A plastic PVC profile is installed at the factory in the left side and right side profile

of the trunking. Remove the plastic profile from the trunking side profile. Lay the carpet over the trunking, cut off the flooring on the inside of

the trunking side profile. The cut-off carpet should be used for covering the blank trunking covers. In the case of hard flooring such as wood

or tiles the flooring should be worked up to the inside of the PVC profile. An appropriate expansion joint has to be considered. Press the butt

joint cover into the slot between the blank trunking covers and the trunking side profile. Do not pull the butt joint cover in a lengthwise direc-

tion.
