Raised floor – Cavity floor – Group connection points
Raised floor – Cavity floor – Cable outlets
Raised floor – Cavity floor – Chains and accessories
Identifier Type Type Altitude
SE = casing element X
V = service unit
Y
E04: eckig147 x 247 mm
E09: cornered 200 x 253 mm
R06: round 215 mm
R2: round 242 mm
R10: round 275 mm
R12: round 306 mm
Q06: square 200 x 200 mm
Q12: square 244 x 244 mm
Q08: square 294 x 294 mm
Z
200 = height 200 mm
Identifier Type Type Colour
LA = cable outlet X
FK = with connection for flat chain
RK = with connection for round chain
TU = tube
BL = blank cover
Y
G20 = clamping range greater
than 20 mm
K20 = clamping range less
than 20 mm
Z
7011 = RAL 7011, iron grey
9005 = RAL 9005, deep black
Identifier Accessories Colour
FK = flat chain Y
1 = length 1 m
A = adapter
B = floor distributor
S = protection (step protection)
H = holder (floor holder)
WB000 = wall and floor holder
Z
7011 = RAL 7011, iron grey
9005 = RAL 9005, deep black
Identifier Accessories Colour
RK = Rundkette Y
1 = length 1 m
R = rosette
A = connection adapter
WH000 = wall holder
Z
7035 = RAL 7035, light grey
