135Technical changes reserved
electraplan.DB-HB
electraplan.DB-HB
Cable outlets with a clamping range less than 20 mm
LAFKK207011
Cable outlet for dry-cleaned floors
Properties:
- With connection for flat chain
Designation PU Order no.
Cable outlet f fl chain clamp<20mm eg 1 LAFKK207011
Cable outlet f fl chain clamp<20mm lg 1 LAFKK207035
Cable outlet f fl chain clamp<20mm ts 1 LAFKK209005
LARKK207011
Cable outlet for dry-cleaned floors
Properties:
- With connection for round chain
Designation PU Order no.
Cable outlet f rd chain clamp<20mm eg 1 LARKK207011
Cable outlet f rd chain clamp<20mm lg 1 LARKK207035
Cable outlet f rd chain clamp<20mm ts 1 LARKK209005
LATUK207011
Cable outlet for wet-cleaned floors
Properties:
- With integrated splashwater protection
Designation PU Order no.
Cable outlet, tube, wet-cleaned fl. clamp<20mm eg 1 LATUK207011
Cable outlet, tube, wet-cleaned fl. clamp<20mm lg 1 LATUK207035
Cable outlet, tube, wet-cleaned fl. clamp<20mm ts 1 LATUK209005
LABLK207011
Blank cover with steel plate inlay
Designation PU Order no.
Cable outlet bl. cov. clamp<20mm eg 1 LABLK207011
Cable outlet bl. cov. clamp<20mm lg 1 LABLK207035
Cable outlet bl. cov. clamp<20mm ts 1 LABLK209005
- For installation in double or
cavity floors
- Clamping range less than
20 mm
- Outer diameter: 132 mm
- Installation opening: 112 mm
Material
Polyamide (halogen-free)
Available colours
RAL 7011, iron grey
RAL 9005, deep black
RAL 7035, light grey
