124
Technical changes reserved
electraplan.AK
On-the-floor
trunking
electraplan.AK
Order number composition
Identifier number Type Trunking width Trunking height Splay/Extension
AK =
On-the-floor trunking
U = Lower part
E = End piece
B8 = Blank cover, length 800 mm
B4 = Blank cover, length 400 mm
BAS =
Blank cover, length 800 mm
,
with connection
BAZ =
Blank cover, length 800 mm
,
with 45 degree junction
BI = Blank cover, inner corner
BA = Blank cover, outer corner
X
150 = 150 mm
200 = 200 mm
250 = 250 mm
300 = 300 mm
350 = 350 mm
400 = 400 mm
Y
040 = 40 mm
070 = 70 mm
Z
1 = single-sided
2 = double-sided
1V = 100 mm extension
On-the-floor trunking
Identifier Type Nominal width Size and type of blanking
AK =
On-the-floor trunking
X
M = Cover with installation
opening
Y
150 = 150 mm
200 = 200 mm
250 = 250 mm
300 = 300 mm
350 = 350 mm
400 = 400 mm
Z
050GBZ = Blanking GBZ round 50 mm
215R06 = Blanking R06 round 215 mm
275R10 = Blanking R10 round 275 mm
306R12 = Blanking R12 round 306 mm
200Q06 = Blanking Q06 200 x 200 mm
294Q08 = Blanking Q08 294 x 294 mm
244Q12 = Blanking Q12 244 x 244 mm
147E04 = Blanking E04 147 x 247 mm
200E09 = Blanking E09 200 x 253 mm
Covers with installation opening
Identifier Type Type Length/Angle
AK =
On-the-floor trunking
X
Z = Accessory
Y
SP = Side profile
SA = Earthing conductor connection
KV = Trunking connector
Z
0100 = Length 100 mm
2400 = Length 2400 mm
0135 = Length 135 mm
090 = angle, 90 degrees
180 = straight, 180 degrees
AK Zubehör
