134 Technical changes reserved
electraplan.DB-HB
electraplan.DB-HB
Cable outlets with a clamping range greater than 20 mm
LAFKG207011
Cable outlet for dry-cleaned floors
Properties:
- With connection for flat chain
Designation PU Order no.
Cable outlet f fl chain clamp>20mm eg 1 LAFKG207011
Cable outlet f fl chain clamp>20mm lg 1 LAFKG207035
Cable outlet f fl chain clamp>20mm ts 1 LAFKG209005
LARKG207011
Cable outlet for dry-cleaned floors
Properties:
- With connection for round chain
Designation PU Order no.
Cable outlet f rd chain clamp>20mm eg 1 LARKG207011
Cable outlet f rd chain clamp>20mm lg 1 LARKG207035
Cable outlet f rd chain clamp>20mm ts 1 LARKG209005
LATUG207011
Cable outlet for wet-cleaned floors
Properties:
- With integrated splashwater protection
Designation PU Order no.
Cable outlet, tube, wet-cleaned fl. clamp>20mm eg 1 LATUG207011
Cable outlet, tube, wet-cleaned fl. clamp>20mm lg 1 LATUG207035
Cable outlet, tube, wet-cleaned fl. clamp>20mm ts 1 LATUG209005
LABLG207011
Blank cover with steel plate inlay
Designation PU Order no.
Cable outlet bl. cov. clamp>20mm eg 1 LABLG207011
Cable outlet bl. cov. clamp>20mm lg 1 LABLG207035
Cable outlet bl. cov. clamp>20mm ts 1 LABLG209005
- For installation in double or
cavity floors
- Clamping range greater than
20 mm
- Outer diameter: 132 mm
- Installation opening: 112 mm
Material
Polyamide (halogen-free)
Available colours
RAL 7011, iron grey
RAL 9005, deep black
RAL 7035, light grey
