6LE008221A
Floor installation systems
Basic manual
Page 22/61
Floor installation systems
Duct systems
A distinction is made between 5 standard floor systems. The appropriate floor system sets
the course from the very start. Depending on the system, only certain products may be used.
Whether this is a screed-covered duct system, which is often used in new buildings, or an on-
floor duct system, which is often used during renovations, the rough direction is entirely differ-
ent. Specific solutions and combination options are available for each system.
The following points, defined in the planning phase, are of decisive importance for the correct
selection of the right duct system:
– Building type (office/administrative building, car showrooms, etc.)
– Building substance (new building, old building with/without protection)
– Building structure (single or open plan offices)
– Use practices (flexible for changes of use)
Screed-covered duct system
Image 7: electraplan.UK
The electraplan.UK floor installation system is quick and easy to install and is suitable for virtually
all types of screed. The underfloor duct and floor boxes made from galvanised sheet steel, which
offers optimal protection against corrosion, are secured to the bare floor. Since the upper sections
of the basic profile are detachable, the cables can be placed into the duct from above and do not
need to be pulled in. The screed is administered flush with the upper edge of the floor boxes such
that the underfloor duct is covered. See catalogue
