Floor structure
Floor structure 50 mm
4 Floor structure
A decisive criterion in the correct selection is the floor structure. The screed height specifies the
amount of play for the underfloor installation. Different products and solutions are used, depending
on the height. It is ever often the case that the screed height is even thinner for reasons of cost. Hager
can offer a range of finished solutions for this. However, should the screed height be extremely low,
then special, project-related special solutions can be provide assistance here.
Fig. 9: Floor structure
4.1 Floor structure 50 mm
Fig. 10: Floor structure 50 mm
The two hinged covers KDQ08x and KDE04x
were developed specially for the requirements, in
which only a screed height of 50 mm or more is
available.
Thanks to their horizontally arranged socket out-
lets in the GBES2x device casing, the hinged
covers are suitable anywhere where the screed
height is only very low. Special solutions can al-
so be used to install data technology in the two
hinged covers.
28
