Basic principles of screed
Screed types
Corrosion:
Corrosion on metallic underfloor components is reduced to a minimum when ...
– The maximum moisture content of screeds corresponds to DIN EN 1264-4.
– Underfloor ducts are ventilated sufficiently for drying.
Hot floor screed:
Screed-flush trunking systems and boxes may not come into direct contact with the hot screed
mass. With film lining, there must be an approx. 10 cm-thick layer of cement screed, for example,
by the components for heat insulation. With metal lining and floor troughs, waterproofed corrugated
card, for example, can be used for insulation. Screed-covered ducts must be protected against the
hot screed mass with 2 - 3 layers of waterproofed corrugated card.
Note!
Avoid cavities!
Hager is not liable for any damaged cause by improper installation on the duct system or
the floor box in conjunction with hot screed!
Expansion pressure of the screed plate:
According to the size of the screed plate and the composition of the screen, it is possible that the
boxes may press against the electraplan.BK duct whilst the screed is hardening. For this, Hager can
offer a matching self-adhesive foam rubber strip (BKZM203), which is fitted in the upper profile area,
in order to reduce the expansion pressure of the screed plate on the duct. The use of the foam rub-
ber strip must be agreed with the screed layer.
