Overview of floor installation systems - cable assignment
Cable assignment, UK ducts
60
28
190
Ducts Trunking width
[mm]
Duct height
[mm]
Version Dimensions
Compartments
[mm]
Usable cross-
section [cm
2
]
Max. cable as-
signment Ø11
mm Filling level
0.5
UK190282 190 28 2-compartment 75/115 53.2 21 (8/13)
UK190283 190 28 3-compartment 60/70/60 53.2 20 (6/8/6)
UK190382 190 38 2-compartment 75/115 72.2 29 (11/18)
UK190383 190 38 3-compartment 60/70/60 72.2 28 (9/10/9)
UK190482 190 48 2-compartment 75/115 91.2 36 (14/22)
UK190483 190 48 3-compartment 60/70/60 91.2 35 (11/13/11)
UK240282 240 28 2-compartment 100/140 67.2 27 (11/16)
UK240283 240 28 3-compartment 85/70/85 67.2 26 (9/8/9)
UK240382 240 38 2-compartment 100/140 91.2 36 (15/21)
UK240383 240 38 3-compartment 85/70/85 91.2 36 (13/10/13)
UK240482 240 48 2-compartment 100/140 115.2 46 (19/27)
UK240483 240 48 3-compartment 85/70/85 115.2 45 (16/13/16)
UK340282 340 28 2-compartment 140/200 95.2 39 (16/23)
UK340283 340 28 3-compartment 115/110/115 95.2 38 (13/12/13)
UK340382 340 38 2-compartment 140/200 129.2 52 (21/31)
UK340383 340 38 3-compartment 115/110/115 129.2 53 (18/17/18)
UK340482 340 48 2-compartment 140/200 163.2 66 (27/39)
UK340483 340 48 3-compartment 115/110/115 163.2 65 (22/21/22)
