Equipotential bonding
13 Equipotential bonding
The certified floor installation system must offer the option of being included in the equipotential bond-
ing.
All the Hager underfloor cable duct systems are constructed in such a way that the connection and in-
clusion in the equipotential bonding is possible without major work.
The earthing clamp BKZSAK00 is used to include the duct system in the equipotential bonding. The
earthing clamp is inserted in the existing grooves and screwed tight. The terminal area is designed for
a conductor cross-section of up to 4 mm².
Touchable, electrically conductive electrical installation duct systems are not included in the protective
equipotential bonding (see Section 411.3.1.2 of DIN VDE 0100-410) and thus are not to be used as an
error protection measure. However, they can, for example, for EMC reasons, be included in the func-
tional equipotential bonding or in the additional protective equipotential bonding and in the lightning
protection equipotential bonding.
Conversely, this means that the resources installed within the electrical installation duct system must
automatically fulfil the requirements for basic protection and error protection. This also includes the
cable systems according to DIN VDE 410 Section 412.2.4.
The floor installation system is an electrical installation duct system and does not fulfil the require-
ments for double insulation (VDE 0100-410 Section 412). This means that the use of conductors with
basic protection (e.g. H07V-K) is not permitted. At least jacketed cables (e.g. NYM-J) must be used,
which end or are connected in suitable jackets (e.g. in boxes or in resources). Strain relief must always
be provided.
52
