Standardisation and testing
Testing
Testing Load class (DIN) EN 50085
6,102.1 500 N
6,102.2 750 N
6,102.3 1000 N
6,102.4 1500 N
6,102.5 2000 N
6,102.6 2500 N
Standard application (tested with test
die Ø13 mm)
6,102.7 3000 N
6,103.1 2000 N
6,103.2 3000 N
6,103.3 5000 N
6,103.4 10000 N
High load (tested with a test plate Ø130
mm)
6,103.5 15000 N
Table 15: Load classes according to (DIN) EN 50085-2-2
Note!
The testing of the floor installation systems with high load requirements may be dealt with
in the standard (DIN) EN 500085-2-2, but the bending during the test (6 mm) permitted in
the standard and that after the test (≤ 3 mm) is not practical. Bending of this magnitude in-
evitably leads to damage to hard floor coverings (e.g. tiles).
Load capacity of screed-covered floor installation systems
Screed-covered duct systems are only subjected to a load during the installation phase. After this,
ducts are “protected” by the screed layer and the traffic loads are distributed across the screed.
In general, it is considered that all screed-covered duct systems must be constructed in such a way so
as to be stable enough to withstand the loads occurring on the construction site during storage, trans-
port and processing.
Further technical information on floor installation systems and their protection classes can
be found in the document 6LE003421A_Schutzarten_Technische Information_de_02-24
.
The document is available in the download area on our homepage www.hager.de.
