EN
Operating manual
PBT 812
Translation of the original
instructions
19
12V SYSTEM TEST
1. Select “SYSTEM TEST” from the main menu.
2. Enter the VIN of the vehicle. (same input method as 6V/12V
Battery Test)
3. Turn o loads and start engine.
4. Use directional keys to review cranking test result.
5. Select “NEXT” to proceed to charging test.
6. “Is it a diesel engine?”
▪ If YES, the tester will ask the user to rev the engine for 40
seconds before proceeding to idle & load on test.
▪ If NO, the tester will proceed with the idle and load on test
directly.
7. Select “NEXT” when idle test is completed and move on to the
ripple & load on test.
8. Turn on loads and rev engine for 15 seconds.
(The tester will countdown 15 seconds)
9. Once completed, the ripple & load test results are displayed.
10. Select NEXT to review the complete system test results including
the cranking, idle, ripple, and load on test results.
11. Use directional keys to switch between 4 dierent pages of the
system test results.
12. Select PRINT if you would like to print out the system test result.
CRANKING TEST RESULTS
1. CRANKING VOLTS NORMAL
The system is showing normal draw. Press «ENTER» to perform the charging system test.
2. CRANKING VOLTS LOW
The cranking voltage is below normal limits, troubleshoot the starter with manufacturers recommended procedure.
3. CRANKING VOLTS NOT DETECTED
The cranking voltage is not detected.
