EN
Operating manual
PBT 812
Translation of the original
instructions
17
6V, 12V BATTERY TEST
1. Select “Battery Test” from the main menu.
2. Select “6V/12V Battery Test”.
3. Select, if necessary, the battery voltage.
The PBT 812 is able to recognise the battery voltage when the
clamps are connected.
Please note that if the voltage of a 12 V battery is too low, the
tester may ask if it is a 6 V battery.
4. Enter VIN via external barcode scanner or manually.
• Scan:
▪ Plug the external barcode scanner into the USB port on the
tester. (only supports USB HID-KBW interface)
▪ Select the QR code icon to enter scan mode. The scanner
will power on.
▪ Scan the VIN code.
▪ Select “NEXT” to proceed.
• Manual input:
▪ Press ENTER when the input area is highlighted to initiate
the virtual keyboard.
▪ Type in the VIN and select “
” to close the virtual key-
board.
▪ Select “NEXT” to proceed.
• Note:
▪ Highlight the “X” icon and press ENTER to clear the input
area.
▪ Skip the process by directly selecting “NEXT”.
▪ Invalid VIN warning will pop up if the VIN does not meet
requirements in terms of length or character. Select “Yes”
to continue without modifying the VIN. Select “No” to return
and reenter the VIN.
5. Select SETUP to change the battery setting.
(The user could click “START” if the battery setting is the same
as the previous test.)
6. Select Battery type
Available types: VRLA/GEL, FLOODED, AGM-FLAT, AGM SPI-
RAL, EFB.
7. Select Standard:
Available standards: CCA/SAE, DIN, EN, EN2, IEC, JIS, CA/MCA
8. Select Capacity
Available capacity range:
♦
25 to 3000 CCA/SAE
♦
25 to 2830 EN
♦
25 to 2710 EN2
♦
25 to 1985 IEC
♦
JIS (by battery type)
♦
25 to 1685 DIN
♦
25 to 3600 CA/MCA
9. Conrm battery position by selecting the YES/NO option of “TEST
IN VEHICLE?”.
10. The tester will then check if the user would like to proceed to an
In-Vehicle Test.
▪ If YES, the tester will automatically proceed to the system test
after the battery test is completed.
▪ If NO, the tester will perform only the battery test.
11. Temperature compensation. Select if battery temperature is
above or below 0 °C / 32 °F.
12. Test result will be presented after test is completed, use directional
keys to review the test result. Select “PRINT” to print test result.
Select “DONE” to return to the main menu.
