EN
11
User manual
KOOLWELD 3
Translation of the original
instructions
SET UP - OPERATING THE DEVICE
Only experienced personnel, authorised by the manufacturer, may set up and install the device. During setup, ensure that the power source is
disconnected from the mains power supply. Serial or parallel power source connections are not allowed.
DESCRIPTION
The KOOLWELD 3 cooling unit is designed to cool liquid TIG torches (L).
The cooling unit is controlled directly by the power source through two connection cables (II-1).
KOOLWELD 3
Power source compatibility
KRYPTON 401 DC
TITANIUM 321 AC/DC
This equipment is equipped with a thermal safeguard to protect the torch against abnormal heating.
This equipment is automatically detected by the power source.
KRYPTON :
In the menu SET UP / Con FIG. :
- Co.U. On: the cooling unit is permanently switched on.
- Co.U. OFF: the cooling unit is switched o.
- Co.U. auto: activates when welding and deactivates the cooling unit 10 minutes after the welding is nished.
TITANIUM:
Select «System/Cooling unit» on the HMI:
- AUTO: activates when welding and deactivates the cooling unit 10 minutes after the welding is nished.
- ON: the cooling unit is permanently switched on.
- OFF: the cooling unit is switched o.
- PURGE : a feature that is designed to purge the cooling unit or ll the water circuit; these safeguarding features are then deactivated.
CONNECTION (I)
The connection or disconnection of the 2 bundles between the generator and the cooling unit must be done with the generator
switched o. Switch o the power supply by unplugging the generator and wait two minutes.
PRODUCT DESCRIPTION (II)
1) Harnesses pre-cables
2) Fuse
3) Fill plug
4) Filling gauge
5) Coolant outlet (blue)
6) Coolant inlet (red)
7) Priming hose
PRIMING THE COOLING UNIT
When used for the rst time or after emptying the tank completely, starting the pump may be dicult and may result in a lack of water ow. Use the
priming hose supplied with the product (II-7) and follow the instructions below to prime it correctly:
- Fill the coolant tank to its maximum level. The tank has a 5.5 litre capacity.
- Connect the priming hose to the coolant outlet blue connector (II-5) and place the other end in an empty container (ideally a bottle).
- Turn on the power source.
KRYPTON :
- Connect a torch to the product, then briey squeeze the trigger to start the pump
- Once the pump is activated (container that lls with coolant), stop the product by turning o the main welding generator switch.
- Disconnect the ignition hose and rell the uid in the cooling unit: the pump is now primed.
TITANIUM :
On the HMI, select «System/Cooling Unit» and click on the icon to start the priming procedure.
- Once the pump is running (with the container lling with coolant), stop the cooling unit by pressing one of the buttons on the HMI.
- Disconnect the ignition hose and rell the uid in the cooling unit: the pump is now primed.
