25
GYSFLASH 51.12 CNT FV / 101.12 CNT / 103.12 CNT / 121.12 CNT FV /
123.12 CNT FV / 125.12 CNT FV / 101.24 CNT FV / 103.24 CNT FV /
51.48 CNT FV / 53.48 CNT FV
EN
25
10 Err11: Time_Out
Triggering the time limit Presence of a consumer on the battery disrupting the charge
Abnormally long charge Battery to be replaced
11 Err12: Q>___Ah Tripping the overcharge protection
Presence of a consumer on the battery disrupting the charge
Battery to be replaced
12 Err13: U<__V
Abnormally low battery voltage when
checking the charge
Battery to be replaced
13 Err14: Bat_UVP
Abnormally low battery voltage during
UVP Wake up
Presence of a short circuit, check the assembly
Battery to be replaced
14 Err15: U<__V Battery too low
Check that the selected mode is compatible with the battery
voltage (e. g. : 24 V battery in 12 V mode)
Battery to be replaced
15 Err16: Bat_NOK Battery out of order Battery to be replaced
16 Err17: Recov_NOK Battery recovery failure Battery to be replaced
17 Err18: U>0V
Presence of a voltage at the clamp
terminals when calibrating the cables
Check the assembly
18 Err19: Cable_NOK Cable calibration failure
Charging cables to be replaced
Incorrect connection, check the assembly
19 Err20: U<__V
Triggering of the abnormal undervol-
tage protection
Presence of a short circuit, check the assembly
20 Err21: U<__V or Err22: U<__V
Abnormally low battery voltage during
charging
Battery to be replaced
Presence of a consumer on the battery
21
?
Key not detected Check that the USB key is correctly connected to the charger.
22
?
No conguration le (.gfc) is present
on the key
Check that your les are present at the root of the USB key. Do
not put them in a folder or sub-folder.
23 Corrupted le
The le you wish to download is corrupted. Delete and reinstall
the le on the key.
24 Err27: Cable_NOK
Multi-charger mode :
Parallel charging cables fail
Load cables to be replaced.
Poor connection, check assembly (PHM).
To switch back to single charger operation, select OFF for the
Multi-Charger function.
25 Err28: COM_NOK
Multi-charger mode :
Communication failure between
chargers
No communication, check SHM mounting and SLAVE X charger
conguration.
To switch back to single charger operation, select OFF for the
Multi-Charger function.
WARRANTY
The warranty covers faulty workmanship for 2 years from the date of purchase (parts and labour).
The warranty does not cover:
• Transit damage.
• Normal wear of parts (eg. : cables, clamps, etc..).
• Damages due to misuse (power supply error, dropping of equipment, disassembling).
• Environment related failures (pollution, rust, dust).
In case of failure, return the unit to your distributor together with:
- The proof of purchase (receipt etc ...)
- A description of the fault reported
