GYSFLASH 51.12 CNT FV / 101.12 CNT / 103.12 CNT / 121.12 CNT FV /
123.12 CNT FV / 125.12 CNT FV / 101.24 CNT FV / 103.24 CNT FV /
51.48 CNT FV / 53.48 CNT FV
EN
24
CHANGE BAT.
Allows to keep the vehicle power supply during battery replacement, in order to preserve the memory of the
vehicle's ECUs.
Caution: Reverse polarity during use can be harmful to the charger and vehicle electronics.
STARTER MODE
Starting aid for combustion vehicles. Allows the battery to be precharged and the charger to send the maximum
current during the engine starting phase (the charger stops automatically after 30 minutes).
POWER SUPPLY
Allows the charger to be used as an adjustable stabilized power supply with high power. The voltage to be regula-
ted and the current limitation are fully adjustable.
Caution: Reverse polarity during use can be harmful to the charger and vehicle electronics.
Li-SUPPLY/LFP
Mode intended to supply lithium-ion cells of the LFP type (Lithium Ferro Phosphate) with selection of the number
of cells in series, adjustment of the voltage and current to be applied.
Li-SUPPLY/Li-ion
Mode intended to supply standard lithium-ion batteries based on Manganese or Cobalt (NMC, LCO, LMO, MCO...)
with selection of the number of cells in series, adjustment of the voltage and current to be applied.
MISCELLANEOUS
TESTER MODE
Allows to check the state of the battery, to evaluate the starting of the vehicle as well as the operation of the
alternator
GYS oers you predened congurations adapted to each application.
These settings are available on the product page of the GYS website:
Conguration le
(gys.fr)
Applications
CHARGE MODE POWER MODES
MIS-
CELLA-
NEOUS
Pb-CHARGE Li-CHARGE TRACTION
SHOWROOM
DIAG+
CHANGE BAT.
STARTER MODE
POWER SUPPLY
Li-SUPPLY/LFP
Li-SUPPLY/Li-ion
TESTER MODE
normal
AGM
water
Easy
Boost
Recovery+
Ca / Ca recov
LFP/LiFePO4
Li-ion std
LFP cell+
Li-ion cell+
water
gel
1_gys_original.gfc Initial conguration of the charger
2_car_extended.gfc Extensive features for garages
3_showroom_only.gfc
Simplied version for dealerships and demons-
tration vehicles
4_pro_lithium.gfc Professional of lithium battery
5_traction.gfc Forklift truck, electric pallet truck, stacker...
6_full_version.gfc Full version
CONNECTIVITY MODULES
Your GYSFLASH is equipped with a DB9 type socket allowing you to connect various additional modules oered by GYS such as a
printer, Ethernet or other module in order to further extend the possibilities of your charger.
LIST OF ERROR CODES
Error code Meaning Solutions
1
Err01: Int_1 - Err02: Int_2
Err23: Int_3 - Err24: Int_4
Electronic problem
Defective charger
Contact the reseller
2 Err03: Fuse_NOK Output fuse out of order Have the fuse replaced by a qualied person
3 Err04: T>Tmax Abnormal overheating Contact the reseller
4 Err05: (+)(-)
The polarity has been reversed on the
clamps
Connect the red clamp to the (+) and the black clamp to the (-)
of the battery.
5 Err06: U>__V
Overvoltage detected at the clamp
terminals
Disconnect the clamps
6 Err07: No_bat Battery not connected Check that the battery is correctly connected to the charger
7 Err08: U<__V Abnormally low battery voltage
Check that the selected mode is compatible with the battery
voltage (e. g. : 6 V battery in 24 V mode)
Charge the battery via CHARGE mode
Battery to be replaced
8 Err09: U>__V Abnormally high battery voltage
Check that the selected mode is compatible with the battery
voltage (e. g. : 24 V battery in 12 V mode)
9 Err10: U>2.0V
Short-circuit detected during the
charge process
Check the assembly
