27
GYSFLASH 108.12 / 148.12 / 158.12 CNT FV
EN
27
• Case 2: Connecting to a load
When the Gysash detects the presence of a contact (e.g.: vehicle without a battery), it will automatically switch to EPS mode.
1
Auto - select
2.5
v
Supply
Contact detection (example: Vehicle without battery)
2
Supply
14.2 V
12 V
EPS
120
A
Launch the associated Supply mode (e.g.: EPS).
EPS
14.2
V
113
A
01:27:35 105.8
Ah
POWER UP MODE
2
1
Power - up
12
V
1- Mode
2- Nominal voltage
Starting the charge:
1 To start the mode, press the START/STOP button.
Power - up
14.0
V
113
A
00:00:25
5.8
Ah
2
1
3
4
5
1- Current mode
2- Voltage supplied by the charger
3- Current supplied by the charger
4- Time remaining
5- Amp-hours delivered
2
Your Gysash will apply a voltage to the lithium battery under
UVP protection to reactivate it.
If the battery is still not reactivated after a while, the charger stops and
indicates an error.
3
When this process is complete, your Gysash will automatically switch to
CHARGE mode (Lithium) to nish charging the battery.
Warning: reversing the polarity during use could damage the charger and
the electronics in the vehicle.
PROTECTIONS
This device is protected against short-circuits and reverse polarity. It features an anti-spark system, which prevents any sparks
when connecting to a battery. If there is no contact on the output, it does not deliver any current for safety reasons. This device is
protected against operator error via an internal fuse.
CONFIGURATION MENU
The conguration menu can be accessed by pressing the button.
